Tektronix MSO70000C/DX Technical Reference page 171

Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
DC gain accuracy (averaged), ≥4 GHz, ≤20 GHz models
Instrument performance test
Ch4 20 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.4 V offset
+5 Div position setting, -0.4 V offset
Ch4 50 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.25 V offset
+5 Div position setting, -0.25 V offset
Ch4 100 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +2.0 V offset
+5 Div position setting, -2.0 V offset
Ch4 200 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +1.25 V offset
+5 Div position setting, -1.25 V offset
Ch4 500 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, 0 V offset
+5 Div position setting, 0 V offset
DC gain accuracy (averaged), ≥4 GHz, ≤20 GHz models
Instrument performance test
Ch1 10 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.45 V offset
+5 Div position setting, -0.45 V offset
Ch1 20 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.4 V offset
+5 Div position setting, -0.4 V offset
Ch1 50 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.25 V offset
+5 Div position setting, -0.25 V offset
Ch1 100 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +2.0 V offset
+5 Div position setting, -2.0 V offset
Ch1 200 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +1.25 V offset
+5 Div position setting, -1.25 V offset
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Minimum Incoming
+ 148.96 mV __________
+ 148.96 mV __________
+ 148.96 mV __________
+ 372.40 mV __________
+ 372.40 mV __________
+ 372.40 mV __________
+ 744.80 mV __________
+ 744.80 mV __________
+ 744.80 mV __________
+ 1.49 V __________
+ 1.49 V __________
+ 1.49 V __________
+ 3.724 V __________
+ 3.724 V __________
+ 3.724 V __________
Minimum Incoming
+ 74.48 mV __________
+ 74.48 mV __________
+ 74.48 mV __________
+ 148.96 mV __________
+ 148.96 mV __________
+ 148.96 mV __________
+ 372.40 mV __________
+ 372.40 mV __________
+ 372.40 mV __________
+ 744.80 mV __________
+ 744.80 mV __________
+ 744.80 mV __________
+ 1.49 V __________
+ 1.849 V __________
+ 1.49 V __________
Outgoing Maximum
__________ + 155.04 mV
__________ + 155.04 mV
__________ + 155.04 mV
__________ + 387.60 mV
__________ + 387.60 mV
__________ + 387.60 mV
__________ + 775.20 mV
__________ + 775.20 mV
__________ + 775.20 mV
__________ + 1.55 V
__________ + 1.55 V
__________ + 1.55 V
__________ + 3.876 V
__________ + 3.876 V
__________ + 3.876 V
Outgoing Maximum
__________ + 77.52 mV
__________ + 77.52 mV
__________ + 77.52 mV
__________ + 155.04 mV
__________ + 155.04 mV
__________ + 155.04 mV
__________ + 387.60 mV
__________ + 387.60 mV
__________ + 387.60 mV
__________ + 775.20 mV
__________ + 775.20 mV
__________ + 775.20 mV
__________ + 1.55 V
__________ + 1.55 V
__________ + 1.55 V
159
