Analog Bandwidth
Performance checks
Bandwidth at Impedance
Channel
Channel 2 50 Ω
MSO5204/B, DPO5204/B, MSO5104/B, DPO5104/B Only
Channel 2 1 MΩ
All Models
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Vertical scale Horizontal
scale
1 mV/div 5 ns/div
(175 MHz)
2 mV/div 2.5 ns/div
(350 MHz)
5 mV/div 1 ns/div
MSO/DPO5204/ (1.5 GHz)
B (Full BW)
MSO/DPO5104/
BMSO/
DPO5054/
BMSO/
DPO5034/B
10 mV/div 1 ns/div
(Full BW)
50 mV/div 1 ns/div
(Full BW)
100 mV/div 1 ns/div
(Full BW)
1 V/div 1 ns/div
(Full BW)
1 mV/div 5 ns/div
(175 MHz)
2 mV/div 2.5 ns/div
(350 MHz)
5 mV/div 1 ns/div
(Full BW)
10 mV/div 1 ns/div
(Full BW)
50 mV/div 1 ns/div
(Full BW)
100 mV/div 1 ns/div
(Full BW)
1 V/div 1 ns/div
(Full BW)
Performance verification (MSO/DPO5000/B series)
V V
in-pp bw-pp
Limit Test result
Gain = V
bw-pp
V
in-pp
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
≥ 0.707
