Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
118
9. Generator, Sine-Wave
Instrument bandwidth
≤3 GHz: 5 kHz to at least the
instrument bandwidth.
Variable amplitude from
60 mV to 2 V into 50 Ω.
p-p
Frequency error <2.0%
Instrument bandwidth
>3 GHz, ≤20 GHz:50 MHz to
at least the instrument
bandwidth. Variable amplitude
from 60 mV to 2.0 V into
p-p
50 Ω. Frequency error <2.0%
Instrument bandwidth
>20 GHz:50 MHz to at least
the instrument bandwidth.
Variable amplitude from
60 mV to 2.0 V into 50 Ω.
p-p
Frequency error <2.0%
10. Meter, Level and Power Sensor
Frequency range: 50 MHz to
the instrument bandwidth.
Amplitude range: 6 mV
p-p
2 V
p-p
11. Splitter, Power
Instrument bandwidth
≤3 GHz: Frequency range:
DC to 18 GHz. Tracking:
<2.0%
Instrument bandwidth
>3 GHz: Frequency range: DC
to 40 GHz. Tracking: <2.0%
12. Cable
2.92 mm male-to-female
13. Adapter
K male-to-male DC to 40 GHz Anritsu K220B
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
1
Fluke 9500B
Anritsu MG3692B or
MG3694B Synthesized CW
Generator with options 2x
(step attenuator), 3 (low noise
>2 GHz), 4 (10 MHz to 2 GHz
low phase noise), 15 (high
power), and 16 (high stability)
Anritsu MG3690C RF/
Microwave Signal Generator
Rohde & Schwarz NRVS and
NRV-Z15 (40 GHz)
to
Agilent part number 11667A
Anritsu K241C (40 GHz)
Gore PhaseFlex cable
EL0CQ0CP0360 (40 GHz)
Checking analog bandwidth,
trigger sensitivity, sample-
rate, external clock, trigger
sensitivity, time qualified
trigger, baud rate limit, clock
recovery, and delay-time
accuracy
Checking analog bandwidth
and trigger sensitivity
Checking analog bandwidth
and trigger sensitivity
Checking analog bandwidth
Checking analog bandwidth
