Test Record - Tektronix MSO70000C/DX Technical Reference

Performance verification (MSO/DPO5000/B series)

Test record

Model
Test
Self Test
Input Impedance
Performance checks Vertical scale
Channel 1 Input 10 mV/div
Impedance, 1 MΩ
100 mV/div
1 V/div
Channel 1 Input 100 mV/div
Impedance, 250 kΩ
Channel 1 Input 10 mV/div
Impedance, 50 Ω
100 mV/div
286
Male-to-male connectors
9. Optical Mouse
USB, PS2
You might need additional cables and adapters, depending on the actual test
equipment you use.
These procedures cover all MSO5000/B series and DPO5000/B series models.
Disregard checks that do not apply to the specific model you are testing.
Print the test record on the following pages and use it to record the performance
test results for your oscilloscope.
NOTE. Completion of the performance verification procedure does not update the
stored time and date of the latest successful adjustment. The date and time are
updated only when the adjustment procedures in the service manual are
successfully completed.
The performance verification procedures verify the performance of your
instrument. They do not adjust your instrument. If your instrument fails any of
the performance verification tests, you should return the instrument to Tektronix
for adjustment or repair.
Serial
Passed
Low limit
990 kΩ
990 kΩ
990 kΩ
246 kΩ
49.5 Ω
49.5 Ω
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Tektronix part number 012-0057-01
Tektronix part number 119-7054-00; standard
accessory for MSO5000/B Series and
DPO5000/B Series oscilloscopes.
Procedure performed by
Failed
Test result
Date
High limit
1.01 MΩ
1.01 MΩ
1.01 MΩ
254 kΩ
50.5 Ω
50.5 Ω
