Tektronix MSO70000C/DX Technical Reference page 71

Trigger specifications (cont.)
Edge trigger sensitivity not DC
coupled, typical
≥4 GHz models
<4 GHz models
Trigger level or threshold range
>20 GHz models
≥4 GHz, ≤20 GHz models
<4 GHz models
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series)
All sources, positive or negative edge, for vertical scale settings ≥10 mV/div and ≤1 V/div
Trigger Coupling
NOISE REJ
AC
HF REJ
LF REJ
Trigger coupling
NOISE REJ
AC
HF REJ
LF REJ
Trigger Source
Any channel
Auxiliary input
Line
Trigger Source
Any channel
Auxiliary input
Line
Trigger Source
Any channel
Auxiliary input
Line
Sensitivity
15%FS from DC to 50 MHz
35%FS at 3 GHz
50%FS at 5 GHz
Same as DC-coupled limits for frequencies >
100 Hz, attenuates signals <100 Hz
Same as DC-coupled limits for frequencies <
20 kHz, attenuates signals > 20 kHz
Same as DC-coupled limits for frequencies >
200 kHz, attenuates signals < 200 kHz
Sensitivity
3 times the DC-coupled limits
Same as DC-coupled limits for frequencies >
100 Hz, attenuates signals <100 Hz
Same as DC-coupled limits for frequencies <
20 kHz, attenuates signals > 20 kHz
Same as DC-coupled limits for frequencies >
200 kHz, attenuates signals < 200 kHz
Range
±100% FS from center of screen
±4.0 V
0 V, Not settable
Range
±120% FS from center of screen
±4.0 V
0 V, Not settable
Range
±12 divisions from center of screen
±5 V
Not settable
59
