Tektronix MSO70000C/DX Technical Reference page 72

Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series)
Trigger level or threshold
accuracy, typical
≥4 GHz models
<4 GHz models
Trigger position error, typical
≥4 GHz models
<4 GHz models
Time range for time-qualified
triggers
≥4 GHz models
<4 GHz models
Time-qualified trigger timer
accuracy
≥4 GHz models
<4 GHz models
60
Edge trigger, DC coupled
Trigger Source
Channel 1, 2, 3, or 4
Auxiliary
Trigger Source
Channel 1, 2, 3, or 4
Auxiliary
Edge trigger, DC coupling, for signals having a slew rate at the trigger point of ≥ 0.5 divisions/ns
Acquisition mode
Sample, Average
Peak Detect, Envelope
Acquisition mode
Sample, Average
Peak Detect, Envelope
Setup/Hold Violation
Timeout
Time qualified window, outside >t
All other types
300 ps to 1 s
For Glitch, Width, Time qualified runt, Transition, or Setup/hold violation types
Time range
Glitch and width triggering (300 ps to 1.0 ns typical)
<300 ns to 1.01 μs
1.02 μs to 1 s
Other time-qualified types (300 ps to 1.0 ns typical)
<300 ps to 1.01 μs
1.02 μs to 1 s
Time range
<1 μs (<2 ns typical)
1 μs to 1 s
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Accuracy
± [(2% | trigger level - net offset | ) + (3.5% FS)
+ offset accuracy]
Not specified
Accuracy
± [(2% | deflection | ) + (0.7 divisions ×
Not specified
Trigger Position Error
± (1 waveform interval + 50 ps)
± (2 waveform intervals + 50 ps)
Trigger Position Error
± (1 waveform interval + 200 ps)
± (2 waveform intervals + 200 ps)
Setup time
Hold time
Setup + hold time
Accuracy
±(3% of setting + 80 ps)
±(TB accuracy + 100 ns)
±(5% of setting + 200 ps)
±(TB accuracy + 20 ns)
Accuracy
±(20% of setting + 0.5 ns)
±(0.01% of setting + 100 ns)
Trigger specifications (cont.)
-100 ns to +100 ns
-1 ns to +100 ns
500 ps minimum
400 ps to 1 s
600 ps to 1 s
300 ps to 1 s
