Serial trigger specifications (cont.)
Clock recovery jitter, typical
≥4 GHz models
<4 GHz models
Clock recovery tracking
acquisition range
≥4 GHz models
<4 GHz models
Minimum signal amplitude needed
for clock recovery, typical
≥4 GHz models
<4 GHz models
Serial interface triggering
standards supported
<4 GHz models
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series)
< 0.25% bit period + 2 ps rms for PRBS data patterns with 50% transition density.
< 0.25% bit period + 1.5 ps rms for repeating 0011 data patterns.
Bit rate Pattern
3.125 GBd 00110011
2.74 GBd 00110011
2.35 GBd 00110011
2.34 GBd 00110011
1.95 GBd 00110011
1.57 GBd 00110011
100 MBd 00110011
10 MBd 00110011
20 ps + 1.25% Unit interval RMS for PRBS data patterns.
RMS
20 ps + 1.25% Unit interval RMS for repeating 0011 data patterns. (Transition density of 50%).
RMS
Jitter increases by 1.4 every time the transition density is reduced by half.
28 ps + 1.25% Unit interval RMS for 25% transition density.
RMS
30 ps + 1.25% Unit interval RMS for 12.5% transition density.
RMS
± 2% of requested baud, data rates below 1.25 GBaud.
± 0.25% of requested baud, data rates above 1.25 GBaud.
± 5% of requested baud
1 division peak-peak up to 1.25 GBd
1.5 divisions peak-peak above 1.25 GBd
Tri-level signals need 50% more pk-pk amplitude
1 division peak-peak up to 1.25 GBd
50% more peak-to-peak amplitude is required for tri-level signals.
2
I C, CAN, SPI, USB1.1, RS232/422/485/UART
Jitter (ps rms)
PRBS 0011
2.8 ps 2.3 ps
2.9 ps 2.4 ps
3.1 ps 2.6 ps
3.1 ps 2.6 ps
3.3 ps 2.8 ps
3.6 ps 3.1 ps
27 ps 27 ps
252 ps 252 ps
