Tektronix MSO70000C/DX Technical Reference page 75

Trigger specifications (cont.)
Window trigger minimum timing
requirements
≥4 GHz models
<4 GHz models
Transition trigger, minimum timing
requirements
≥4 GHz models
<4 GHz models
Transition trigger delta time range
Setup-Hold violation trigger, setup
and hold time ranges
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series)
Window enters
Window exits
Logic qualified window enters
Logic qualified window exits
Window inside >t
Window outside >t
Window
Logic qualified window
The transition trigger event occurs at the end of the transition. The logic condition must be valid at
the moment the transition event occurs minus the setup time plus the hold time. Rearm time is the
time below the lower threshold and the time above the upper threshold. Neither time can be
violated.
Transition type
Logic qualified transition type
Transition type
Logic qualified transition type
1 ns to 1 s
Setup time
Hold time
Setup + hold time
Minimum Minimum
pulse width rearm time
150 ps 500 ps
500 ps 150 ps
150 ps 500 ps
500 ps 150 ps
N.A. 500 ps
N.A. 150 ps
Minimum Minimum
pulse width rearm time
225 ps 300 ps
190 ps 300 ps
Minimum Minimum
pulse width rearm time
0 ps 500 ps
0 ps 500 ps
Minimum Minimum
pulse width rearm time
0 ps 225 ps
330 ps 225 ps
Minimum
-100 ns
-1 ns
500 ps
Setup time Hold time
N.A. N.A.
N.A. N.A.
N.A. N.A.
N.A. N.A.
N.A. N.A.
N.A. N.A.
Setup time Hold time
N.A. N.A.
-20 ps 0 ps
Setup time Hold time
N.A. N.A.
50 ps 50 ps
Setup time Hold time
N.A. N.A.
225 ps 175 ps
Maximum
100 ns
102 ns
63
