Tektronix MSO70000C/DX Technical Reference page 162

Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
DC gain accuracy (averaged), >20 GHz models
Instrument performance test
Ch2 100 mV Vert scale setting,
0 V termination
0 Div position setting, 0 V offset
0 Div position setting, +1 V offset
0 Div position setting, -1 V offset
+1.5 V termination
0 Div position setting, +2.5 V offset
0 Div position setting, +1.5 V offset
0 Div position setting, +0.5 V offset
+3.4 V termination
0 Div position setting, +3.4 V offset
0 Div position setting, +2.4 V offset
-3.4 V termination
0 Div position setting, -3.4 V offset
0 Div position setting, -2.4 V offset
-1.5 V termination
0 Div position setting, -1.5 V offset
0 Div position setting, -0.5 V offset
Ch2 120 mV Vert scale setting,
0 V termination
0 Div position setting, 0 V offset
0 Div position setting, +1 V offset
0 Div position setting, -1 V offset
+1.5 V termination
0 Div position setting, +2.5 V offset
0 Div position setting, +1.5 V offset
0 Div position setting, +0.5 V offset
+3.4 V termination
0 Div position setting, +3.4 V offset
0 Div position setting, +2.4 V offset
-3.4 V termination
0 Div position setting, -3.4 V offset
0 Div position setting, -2.4 V offset
-1.5 V termination
0 Div position setting, -1.5 V offset
0 Div position setting, -0.5 V offset
Ch2 140 mV Vert scale setting,
0 V termination
0 Div position setting, -1 V offset
0 Div position setting, 0 V offset
0 Div position setting, +1 V offset
Ch2 200 mV Vert scale setting,
0 V termination
0 Div position setting, -0.9 V offset
0 Div position setting, 0 V offset
0 Div position setting, +0.9 V offset
150
Minimum
+ 588 mV
+ 588 mV
+ 588 mV
+ 588 mV
+ 588 mV
+ 588 mV
+ 588 mV
+ 588 mV
+ 588 mV
+ 588 mV
+ 588 mV
+ 588 mV
705.6 mV
705.6 mV
705.6 mV
705.6 mV
705.6 mV
705.6 mV
705.6 mV
705.6 mV
705.6 mV
705.6 mV
705.6 mV
705.6 mV
823.2 mV
823.2 mV
823.2 mV
1176 mV
1176 mV
1176 mV
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Incoming Outgoing
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
Maximum
+ 612 mV
+ 612 mV
+ 612 mV
+ 612 mV
+ 612 mV
+ 612 mV
+ 612 mV
+ 612 mV
+ 612 mV
+ 612 mV
+ 612 mV
+ 612 mV
734.4 mV
734.4 mV
734.4 mV
734.4 mV
734.4 mV
734.4 mV
734.4 mV
734.4 mV
734.4 mV
734.4 mV
734.4 mV
734.4 mV
856.8 mV
856.8 mV
856.8 mV
1224 mV
1224 mV
1224 mV
