Analog channel input and vertical specification (cont.)
Offset ranges, minimum
Position range
Offset accuracy
Number of waveforms for average
acquisition mode
DC voltage measurement accuracy
average acquisition mode
DC voltage measurement
accuracy, sample acquisition
mode, typical
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Volts/div setting
1 mV/div to 50 mV/div
50.5 mV/div to 99.5 mV/div
100 mV/div to 500 mV/div
505 mV/div to 995 mV/div
1 V/div to 5 V/div
5.05 V/div to 10 V/div
For 50 Ω path, 1 V/div is the maximum vertical setting.
The input signal cannot exceed Max Input Voltage for the 50 Ω input path. Refer to the Max Input
Voltage specification for more information.
±5 divisions
±[0.005 × | offset - position | + DC Balance]
Both the position and constant offset term must be converted to volts by multiplying by the
appropriate volts/div term.
2 to 10,000 waveforms
Default of 16 waveforms
Average of ≥ 16 waveforms
Delta Volts between any two averages of
≥16 waveforms acquired with the same
oscilloscope setup and ambient conditions
Note: Offset, position, and the constant offset term must be converted to volts by multiplying by the
appropriate volts/div term.
The basic accuracy specification applies directly to any sample and to the following
measurements: High, Low, Max, Min, Mean, Cycle Mean, RMS, and Cycle RMS. The delta volt
accuracy specification applies to subtractive calculations involving two of these measurements.
The delta volts (difference voltage) accuracy specification applies directly to the following
measurements: Positive Overshoot, Negative Overshoot, Peak-to-Peak, and Amplitude.
Specifications (MSO/DPO5000/B Series)
Offset range
1 MΩ input
±1 V
±0.5 V
±10 V
±5 V
±100 V
±50 V
±[DC Gain Accuracy × | reading – (offset -
position) | + offset accuracy + 0.1 division ]
Refer to DC Gain Accuracy for temperature
derating information.
±[DC gain accuracy × | reading | + 0.05 div]
Refer to DC Gain Accuracy for temperature
derating information.
50 Ω input
±1 V
±0.5 V
±10 V
±5 V
±5 V
Not applicable
