Tektronix MSO70000C/DX Technical Reference page 15

Vertical system analog channels (cont.)
series)
Input resistance ≥4 GHz
≤20 GHz models
100 mV to 995 mV :
FS FS
1 V to 5 V :
FS FS
Input impedance DC coupled
<4 GHz models
1 MΩ, DC coupled
50 Ω, DC coupled
Maximum input voltage range
>20 GHz models
≤1.2 VFS settings:
>1.2 VFS settings:
Maximum input voltage ≥4 GHz
and ≤20 GHz models
<1.0 V/Full Scale settings:
≥ 1.0 V/Full Scale settings:
Maximum input voltage <4 GHz
models
1 MΩ – DC coupled
1 MΩ – AC coupled, or GND
coupled
50 Ω
Measurement category for MSO-
DPO70K and DPO7K series only
Input termination voltage (VTerm)
range >20 GHz models
≤1.2 VFS settings:
>1.2 VFS settings:
Input termination voltage (VTerm)
range ≤20 GHz models
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
50 Ω ±1.5% at 25 ºC (77 ºF)
50 Ω ±2% over 10 to 45 ºC (50 to 113 ºF), type tested
50 Ω ±2.2 Ω over 10 to 45 ºC (50 to 113 ºF), type tested
1 MΩ ± 1% in parallel with 13 pF ± 2 pF
50 Ω ± 1%, typical
±1.5 V relative to the termination bias (30 mA maximum)
±5 V absolute maximum input
8 V. Limited by maximum Vterm current and the attenuator power rating at maximum temperature.
±3.3 V Maximum
±5.0 V Maximum
150 V. Derate at 20 dB/decade to 9 VRMS above 200 kHz.
The maximum input voltage at the BNC, between center conductor and ground is 400 V peak. The
RMS voltage is limited to <150 V for arbitrary waveshapes including DC. The maximum pulse width
for impulses with peaks over 150 V is 50 μs. Example: At 0 V to 400 V peak, rectangular wave, the
duty factor is 14%.
The maximum transient withstand voltage is ± 800 V peak.
5 V RMS, with peaks ≤ ± 24 V
The measuring terminals on this product are not rated for connection to mains or Measurement
Category II, III or IV circuits.
-3.5 V to +3.5 V
0 V
0 V
