Emerson Fisher FIELDVUE DVC6000f Instruction Manual page 331

PlantWeb Alert
Alert Condition
(Group)
and (Default))
(Default Alert Category
Travel Sensor Travel Sensor
(Sensors) (Enabled)
(Failed)
Output Press Sensor Port A Pressure
(Sensors) Sensor (Enabled)
(Maintenance)
Port B Pressure
Sensor (Enabled)
Supply Press Sensor Supply Press
(Sensors) Sensor (Enabled)
(Advisory)
Temperature Sensor Temperature
(Sensors) Sensor (Enabled)
(Advisory)
December 2009
Table C-3. Using PlantWeb Alerts (Continued)
What the Alert is
Detecting
The travel feedback is within If configured for Self Test
acceptable limits. Shutdown, then the
transducer "Actual" mode is
placed Out of Service until the
problem is fixed. Out of
service results in the actuator
being at the Zero Power
Condition.
The pressure sensor reading If configured for Self Test
is outside the functional range Shutdown, then the
of the sensor.
transducer "Actual" mode is
placed Out of Service until the
problem is fixed. Out of
service results in the actuator
being at the "No Power"
condition.
None − Indicates a possible
hardware problem that would
degrade diagnostic capability.
None − Indicates a possible
The pressure sensor reading
is outside the functional range hardware problem that would
of the sensor. degrade diagnostic capability.
None − Indicates a possible
The temperature sensor
reading is outside the hardware problem that would
functional range of the sensor. degrade instrument calibration
and diagnostic capability.
−Continued−
Using PlantWeb Alerts
Effect on Valve / Recommended
Instrument Action
Check mounting
and linkage
Confirm proper
air supply
Confirm proper
air supply
Replace PWB
assembly.
Help
Travel feedback value
is outside expected
limits. If this problem
occurs during
instrument set-up, the
most likely cause is
faulty mounting or
improper adjustment of
the travel sensor. If
this problem occurs
during normal
operation, the most
likely cause is a failure
of the travel sensor or
damaged linkage.
To correct,
1) Insure proper
mounting and linkage
adjustment.
2) Inspect and test
travel sensor
3) Toggle the
transducer target
mode.
If the problem persists,
replace the printed
wiring board (PWB)
assembly.
The pressure sensor
on-board the device
has failed. This may
be due to excessive
supply pressure or
contaminated air.
If it is verified that the
air supply is ok,
replace the printed
wiring board (PWB)
assembly.
The pressure sensor
C
on-board the device
has failed. This may
be due to excessive
supply pressure or
contaminated air.
If it is verified that the
air supply is ok,
replace the printed
wiring board (PWB)
assembly.
The temperature
sensor on-board the
device has failed or
the unit has been
exposed to an
temperature extreme
beyond the
recommended limits.
C-9
