DVC6000f Digital Valve Controllers
Key Description
PWB Assembly
Note
Contact your Emerson Process
Management sales office for PWB
Assembly FS Numbers.
Key Description
50* PWB Assembly
Standard Control
Fieldbus Diagnostics
Advanced Diagnostics
Performance DIagnostic
Fieldbus Control
Fieldbus Diagnostics
Advanced Diagnostics
Performance Diagnostics
Fieldbus Logic
Fieldbus Diagnostics
Advanced Diagnostics
Performance Diagnostics
8
72 Cap Screw, hex socket
for DVC6010f, DVC6020f, DVC6015, and DVC6025
(2,18)
78 Bias Spring, SST
for DVC6010f, DVC6030f, DVC6015 and DVC6035
79 Feedback Arm
for DVC6010f, DVC6015, DVC6030f and DVC6035
80 Cap Screw, hex socket, SST
(2,18)
81 Square Nut, SST
(18)
104 Cap Screw, hex hd
Aluminum Construction
DVC6010f and DVC6015
Not for mounting on 1250 and 1250R actuators.
Mounting parts for 1250 and 1250R actuators are
included in the mounting kit for these actuators.
(4,18)
107 Mounting Bracket
Not for mounting on 1250 and 1250R actuators.
Mounting parts for 1250 and 1250R actuators are
included in the mounting kit for these actuators.
- - - Feedback Linkage Shield, see figures 2-1 and 2-2
Up to 50.4 mm (2 inch) travel
All sliding-stem actuators except 585C size 60
50.4 mm (2 inch) to 104mm (4 inch) travel
All sliding-stem actuators except 585C size 60
585C size 60, 19 mm (0.75 inch) to
104mm (4 inch) travel
(2,18)
163 Plain Washer, SST
8-6
Part Number
Part Number
(2,18)
(2 req'd)
(2,18)
(4 req'd)
, DVC6010f and DVC6015 only
39B2268X012
49B2267X012
49B3844X012
Key Description
223* Potentiometer/Bushing Assy
Standard Elastomers
DVC6010f, DVC6020f
DVC6030f
Extreme Temperature option (fluorosilicone elastomers)
DVC6010f and DVC6020f
DVC6030f
DVC6015 and DVC6025
(18)
DVC6035
DVC6020f and DVC6025
(see figures 8-3 and 8-8)
74 Mounting Bracket, DVC6025 only
(also in Housing parts for DVC6020f)
(3)
82 Bias Spring, SST
83 Bearing Flange, PTFE-based
(3)
84 Feedback Arm Assy, SST
(3)
85 E-ring, pl stl (2 req'd)
(3)
86 Plain Washer, pl stl (2 req'd)
(3)
87 Follower Post, SST
(3)
88 Roller, SST/PTFE
(3)
89 Spring Lock Washer, pl stl
(3)
90 Hex Nut, pl stl
91 Arm Assy, SST
(3)
92 Cap Screw, hex socket (4 req'd)
93 Torsion Spring, Feedback Arm
DVC6015, DVC6025, and DVC6035
(see figures 8-7, 8-8, and 8-9)
(18,20)
23 Cap Screw, hex socket
(18,20)
44 Wire Retainer, pl stl (9 req'd)
49 Screw, self tapping (2 req'd)
(18)
58 Set Screw, hex socket
(18)
62 Pipe Plug, hex hd, SST
131 Retainer Wire
(18)
251 Feedback housing
(18)
252 Assembly Plate Shield (DVC6015 only)
(18,20)
253 Terminal bracket
(18,20)
254 Terminal Strip
(18)
255 Terminal Cap
(18)
256 O-ring, fluorosilicone
(18)
257 Machine Screw, pan head
(18)
258 Label, cover
260 Hex Nut, SST (2 req'd)
261 Nameplate
(18)
265 Plug (DVC6015 and DVC6035 only)
*Recommended spare
2. Available in the Small Hardware Spare Parts Kit
3. Available in the DVC6010f to DVC6020f Conversion Kit
4. Available in the DVC6020f to DVC6010f Conversion Kit
18. Available in Feedback Unit Kit
20. Available in Feedback Unit Termination Strip Kit
Part Number
GE31447X012
GE31448X012
GE31450X012
GE31451X012
(18)
GE31453X012
GE31454X012
(3)
(2 req'd)
(3)
(2 req'd)
(2 req'd) (DVC6015 only)
