Emerson Fisher FIELDVUE DVC6000f Instruction Manual page 157

Table 4-31. PID Function Block System Parameters Definitions (Continued)
Label Index
PARAMETER_NAME Number
T Auto Extra DT
90
T_AUTO_EXTRA_DT
T Auto Hysteresis
91
T_AUTO_HYSTERESIS
T Aoperiods
92
T_AOPERIODS
December 2009
RO / Block
Range
RW Mode
ALL
ALL
RO N/A
PID Function Block
Initial Value Description
Data Type: Unsigned8
0
Allow additional cycle with extra deadtime.
Data Type: Unsigned8
0 Allows calculation of hysteresis based on
CAP_STDDEV
Data Type: Unsigned8
0
Actual oscillation periods.
4
4-97
