Emerson Fisher FIELDVUE DVC6200p Instruction Manual Supplement

Instruction Manual Supplement
D104172X012
™
Fisher FIELDVUE
PACTware 4.1
This document takes your through establishing a connection to PROFIBUS PA device DVC6200p in Pactware 4.1
through PROFIusb USB and the installation of the supported DTM.
Notes
The information found in this document can also be used to establish connections to FieldCare™ and FieldMate configuration
tools.
Refer to the DVC6200 Series Quick Start Guide, D103556X012, for DVC6200p installation, connection, and initial configuration
information and the DVC6200p Instruction Manual, D103563X012, for all other information pertaining to the DVC6200p digital
valve controller, including product specifications, reference materials, custom setup information, maintenance procedures, and
replacement part details.
DTM Supported:
DVC6200p_Profibus_DTM
Assumptions and Supported Environment:
The following software and hardware should be installed prior to launching the DVC6200p DTM in PACTware 4.1.
S. No
1 PD to PA Coupler (Pepperl and Fuchs)
2. PROFIusb USB
3. PROFIBUS CommDTM
4. Pactware 4.1
www.Fisher.com
™
DVC6200p DTM with
System
Compact PROFIBUS
Power Hub and Segment
Coupler KT-MB-GTB-2PS
H/W V1.03
Driver Ver. 5.45.11
FROFIdtm
Ver 4.1
DVC6200p Digital Valve Controller
Version Reference Link
http://www.pepperl-fuchs.u
s/usa/en/classid_1482.htm?
view=productdetails&prodid
=36114
Drivers included with
CD/DVD when purchased
PROFIbus DTM
PACTware 4.1 from
pepperl-fuchs
November 2017
