DOUBLE-ACTING
APPLY LUB, SEALANT
NOTE:
1
FOR SINGLE-ACTING DIRECT, OUTPUT B IS PLUGGED.
FOR SINGLE-ACTING REVERSE, OUTPUT A IS PLUGGED.
2
48B7710-K SHT 2 / DOC
Figure 8-6. Typical FIELDVUE DVC6000f Digital Valve Controller Gauge Configuration
SECTION B‐B
APPLY LUB, SEALANT
NOTE:
1. APPLY LUBRICANT KEY 65 TO ALL O-RINGS UNLESS OTHERWISE SPECIFIED
48B7986-A
December 2009
SINGLE-ACTING DIRECT
SECTION A‐A
Figure 8-7. FIELDVUE DVC6015 Digital Valve Controller Assembly
1
SINGLE-ACTING REVERSE
Parts
2
SECTION C‐C
SECTION D‐D
8-13
8
