Emerson Fisher FIELDVUE DVC6000f Instruction Manual page 108

DVC6000f Digital Valve Controllers
Label
PARAMETER_NAME
TRAVEL_CAL_RUN
4
Travel Calibration Command
TVL_CAL_CMD
Travel Calibration Prog
TVL_CAL_PROG
Travel Calibration Status
TVL_CAL_STATUS
Reserved
TVL_CAL_RESERVED
4-48
Table 4-13. Transducer Block Parameter Definitions (Continued)
Index RO /
Mode Range
Number RW
45
1: Operating
2: Autocalibrate
3: Mark Crossover
4: Mark Full Open
5: Mark Full Closed
6: Manual Calibrate Final
7: Abort
8: Clear Cal Status
9: Manual Calibrate Init
10: Manual Calibrate
Restore
11: Reset Travel Sensor
Error
12: Reserved
13: Execute
45.1 RW MAN
Performance Tuner
14: Execute
Performance Tuner
(Graphite Packing)
16: Execute
Performance Tuner
(Booster)
17: Execute
Performance Tuner
(Graphite Packing and
Booster)
19: Autocalibration, Set
Filter
20: Autocalibrate
Extended, Set Filter
45.2 RO N/A
0: auto cal complete
1: calibration complete
2: auto cal in progress
3: manual cal in
progress
4: crossover marked
5: upper position marked
6: lower position marked
7: calibration error
8: Performance Tuner
45.3 RO N/A
active
9: Performance Tuner
Success
10: Performance Tuner
Error (No movement)
11: Performance Tuner
Error (Accessories
unstable)
12: Performance Tuner
Error (Other)
45.4
−Continued−
Protect
Initial Value
Category
Data Type: Enum (Uint8)
1=Operating CAL
Resets to 1 after a write
0% N/A Data Type: Uint8
Data Type: Bit String (2 bytes)
All bits set to 0 when mode
no bits set N/A
changes from OOS. 0 = FALSE,
1 = TRUE
Reserved
Description
December 2009
