DVC6000f Digital Valve Controllers
View Lists
View lists allow the values of a set of parameters to be
accessed at the same time. Views 1 and 2 contain
operating parameters and are defined by the Fieldbus
Foundation. View 3 contains dynamic parameters and
View 4 contains static parameters with configuration
and maintenance information. Views 3 and 4 are
defined by the manufacturer.
Table 4-14. Transducer Block, View 1
Index Number
1 ST_REV
5.1 MODE_BLK.TARGET
5.2 MODE_BLK.ACTUAL
5.3 MODE_BLK.PERMITTED
4
5.4 MODE_BLK.NORMAL
6 BLOCK_ERR
10 TRANSDUCER_TYPE
11 XD_ERROR
13.1 FINAL_VALUE.STATUS
13.2 FINAL_VALUE.VALUE
17.1 FINAL_POSITION_VALUE.STATUS
17.2 FINAL_POSITION_VALUE.VALUE
32.1 SETPOINT_D.STATUS
32.2 SETPOINT_D.VALUE
Table 4-15. Transducer Block, View 2
Index Number
1 ST_REV
10 TRANSDUCER_TYPE
14.1 FINAL_VALUE_RANGE
14.2
FINAL_VALUE_RANGE
14.3
FINAL_VALUE_RANGE
14.4 FINAL_VALUE_RANGE
15 FINAL_VALUE_CUTOFF_HI
16 FINAL_VALUE_CUTOFF_LO
18 SERVO_GAIN
19 SERVO_RESET
20 SERVO_RATE
21 ACT_FAIL_ACTION
40.1
GRANT_DENY.
40.2 GRANT_DENY.
50 INPUT_CHAR
4-64
Parameter
Parameter
.EU_100
.EU_0
.UNITS_INDEX
.DECIMAL
GRANT
DENY
Note
Because individual views are limited in
size, View Lists 3 and 4 have multiple
parts.
Table 4-16. Transducer Block, View 3.1
Index Number
1 ST_REV
5.1 MODE_BLOCK.TARGET
5.2 MODE_BLOCK.ACTUAL
5.3 MODE_BLOCK.PERMITTED
5.4 MODE_BLOCK.NORMAL
6 BLOCK_ERR
10 TRANSDUCER_TYPE
11 XD_ERROR
13.1 FINAL_VALUE.STATUS
13.2 FINAL_VALUE.VALUE
17.1 FINAL_POSITION_VALUE.STATUS
17.2 FINAL_POSITION_VALUE.VALUE
32.1 SETPOINT_D.STATUS
32.2 SETPOINT_D.VALUE
35.1 SUPPLY_PRESSURE.STATUS
35.2 SUPPLY_PRESSURE.VALUE
36.1 PRESSURE_A.STATUS
36.2 PRESSURE_A.VALUE
37.1 PRESSURE_B.STATUS
37.2 PRESSURE_B.VALUE
38.1 PRESSURE_DIFF.STATUS
38.2 PRESSURE_DIFF.VALUE
48 TEMPERATURE
49 TRAVEL_TARGET
52 TRAVEL_DEVIATION
53 DRIVE_SIGNAL
54 DRIVE_CURRENT
55 MLFB
59 FAILED_ACTIVE
60 MAINT_ACTIVE
61 ADVISE_ACTIVE
71 RECOMMEND_ACTION
72 TRAVEL_ACCUM
73 CYCLE_COUNT
75.1 INST_ALERTS_ENABLE.ELECT_ENABLE
75.2 INST_ALERTS_ENABLE.SENSOR_ENABLE
75.3 INST_ALERTS_ENABLE.ENVIRO_ENABLE
75.4 INST_ALERTS_ENABLE.TRAVEL_ENABLE
75.5 INST_ALERTS_ENABLE.PROX_ENABLE
75.6 INST_ALERTS_ENABLE.TVL_HISTORY_ENABLE
75.7 INST_ALERTS_ENABLE.PERF_ENABLE
Parameter
