Viewing Device Variables and Diagnostics
Pressure B Sensor Failure—Indicates the pressure
sensor is reporting a pressure that is significantly
outside of the normal operating pressure, and has
failed.
Pressure A Sensor Failure—Indicates the pressure
sensor is reporting a pressure that is significantly
outside of the normal operating pressure, and has
failed.
Supply Sensor Failure—Indicates the pressure sensor
is reporting a pressure that is significantly outside of
the normal operating pressure, and has failed.
IOP Failure—Indicates the I/O processor has failed.
Drive Current Alert—Indicates that the Drive Current
has exceeded the Drive Current Alert Point for more
than the Drive Current Alert Time.
Simulate Jumper ON—Indicates the simulate jumper
is connected to the DVC6000f between the two AUX
terminals.
Block Error
Table 6-2 lists conditions reported in the BLOCK_ERR
[6] and XD_ERROR [11] parameters. Conditions in
italics are not applicable for the transducer block and
are provided only for your reference.
Table 6-2. Transducer Block BLOCK_ERR and
XD_ERROR Conditions
Condition
Condition Name and Description
Number
0 Other - (N/A)
Block Configuration Error - Indicates that one of the
1 following parameters have been configured out of the
proper range: 15, 16, 47.1, 47.2, 46.3, 46.5, 42.7, 42.8.
2 Link Configuration Error - (N/A)
Simulate Active - Indicates that alerts are being
simulated. This is not an indication that the I/O blocks are
3 using simulation data. See AO block parameter
SIMULATE [10] and DO block parameter SIMULATE_D
[10].
4 Local Override - (N/A)
Device Fault State − (NA)
5
6 Maintenance Needed Soon - (N/A)
7 Input failure/process variable has Bad status - (N/A)
8 Output failure - (N/A)
9 Memory failure - (N/A)
Lost Static Data - Indicates that manufacturing functional
10
or thermal tests were incomplete
11 Lost NV Data - (N/A)
12 Readback Check Failed - (N/A)
Device Needs Maintenance Now - Indicates that
13
manufacturing functional or thermal tests were incomplete
14 Power Up - (N/A)
15 Out of Service - Indicates Out of Service Mode.
December 2009
Device Record
(TB > Device Diagnostics > Device Record )
The following parameters are contained in the Device
Record menu of the transducer block.
D Maximum Recorded Temperature
Maximum Recorded Temperature (TEMP_MAX [86.1])
shows the maximum temperature the instrument has
experienced since installation.
D Maximum Recorded Temperature Time
Maximum Recorded Temperature Time
(TEMP_MAX_TIME [86.2]) shows the date and time
when the Temperature Maximum occurred.
D Minimum Recorded Temperature
Minimum Recorded Temperature (TEMP_MIN [86.3])
shows the minimum temperature the instrument has
experienced since installation.
D Minimum Recorded Temperature Time
Minimum Recorded Temperature Time
(TEMP_MIN_TIME [86.4]) shows the date and time
when the Temperature Minimum occurred.
D Maximum Recorded Supply Pressure
Maximum Recorded Supply Pressure
(SUPPLY_PRESS_MAX [86.5]) shows the maximum
supply pressure the instrument has experienced since
installation.
D Maximum Recorded Supply Pressure Time
Maximum Recorded Supply Pressure Time
(SUPP_PRESS_MAX_TIME [86.6]) shows the date
and time when the Supply Pressure Maximum
occurred.
D Minimum Recorded Supply Pressure
Minimum Recorded Supply Pressure
(SUPP_PRESS_MIN [86.7]) shows the minimum
supply pressure the instrument has experienced since
installation.
D Minimum Recorded Supply Pressure Time
Minimum Recorded Supply Pressure Time
(SUPP_PRESS_MIN_TIME [86.8]) shows the date
and time when the Supply Pressure Minimum
occurred.
