DVC6000f Digital Valve Controllers
Table 4-79. BLOCK_ERR Conditions
Condition
Condition Name and Description
Number
0
Other (N/A)
Block Configuration Error—CHANNEL set to 0 through 10
1
(uninitialized)
2
Link Configuration Error (N/A)
Simulate Active—Simulate is enabled. Output does not
3
reflect process conditions
4
Local Override (N/A)
5
Device Fault State Set (N/A)
6
Device Needs Maintenance Soon (N/A)
Input failure/process variable has Bad status—The
7
hardware is bad or the transducer block mode is Out of
Service
8
Output Failure (N/A)
4
9
Memory Failure (N/A)
10
Lost Static Data (N/A)
11
Lost NV Data (N/A)
12
Readback Check Failed (N/A)
13
Device Needs Maintenance Now (N/A)
Power Up—Set after power-up until actual mode is not Out of
14
Service
Out of Service—The actual mode is Out of Service (OOS).
15
The block is not being processed.
Block Errors
Table 4-79 lists conditions reported in the
BLOCK_ERR [6] parameter. Conditions in italics are
not applicable for the DI block and are provided only
for your reference.
Action on Failure
In case of hardware failure, FIELD_VAL_D [17], PV_D
[7], and OUT_D [8] change to a Bad status and the
BLOCK_ ERR [6] parameter shows Process Variable
has Bad Status. If the transducer block mode is Out of
Service, the status of FIELD_VAL_D [17], PV_D [7],
and OUT_D [8] is set to Bad:Out of Service.
Simulation
To support testing of the control strategy, you can
enable the SIMULATE_D [9] parameter. Normally the
measurement value and status used for
FIELD_VAL_D [17] in the DI block reflect actual
process values as provided by the transducer block.
When the SIMULATE_D [9] parameter is enabled,
value and status used for FIELD_VAL_D [17] is
supplied by the user manually. To enable simulation in
the DI function block, the simulate jumper must be
4-164
STANDARD DISCRETE INPUT
PROXIMITY DISCRETE INPUT
Configurable
Band
Figure 4-33. Proximity Discrete Input Compared to a
Standard Discrete Input
installed. For information on the installation of this
jumper, see the Installation section.
The SIMULATE_D [9] parameter has three
components:
D Simulate_D enable/disable determines whether
the function block will use the actual process value
and status, or Simulate Value and Simulate Status.
D Transducer Value and Status reflect the process
values provided by the transducer block.
D Simulate Value and Status may be entered by
the user when enable/disable is set to enabled.
To use simulate, first install the simulate jumper in the
terminal box, then set Simulate_D enable/disable to
enabled, then enter the desired values for Simulate
Value and Status.
DISCRETE INPUT
1
VALUE
0
DISCRETE INPUT
0
VALUE
1
0
December 2009
