DVC6000f Digital Valve Controllers
Parts List
Parts which do not show part numbers are not
orderable as individual parts. In most cases, they are
available in one of the parts kits listed under Parts
Kits.
Note
Parts with footnote numbers shown
are available in parts kits. Also see
footnote information at the bottom of
the page.
Key
Description
Housing
DVC6010f, DVC6020f, DVC6030f, DVC6005f
(see figures 8-2, 8-3, 8-4, and 8-5)
(14)
1
Housing
(14)
11
Drive Screw
(2 req'd)
(14)
20
Shield
(2)
52
Vent, plastic
DVC6010f, DVC6030f, and DVC6005f only
74
Mounting Bracket
(3)
DVC6020f Std
or pipe-away
(7)
75*
O-Ring
, DVC6020f only
8
(7)
245
Pipe Plug, pl stl
, DVC6020f Vent-away only
(21)
248
Screw, hex head
(4 req'd), (DVC6005f only)
(21)
249
Screw, hex head
(4 req'd), (DVC6005f only)
(21)
250
Spacer
(4 req'd), (DVC6005f only)
(21)
267
Standoff
(2 req'd), ( (DVC6005f only)
(14)
271
Screen
Common Parts
(1)
16*
O-ring
(3 req'd)
23
Cap Screw, hex socket, SST
29
Warning label, for use only with LCIE hazardous area
classifications
33
Mach Screw, pan hd, SST
38
Cap Screw, hex socket, SST
43*
Cover Assembly (includes cover screws)
Aluminum Construction
Standard
Extreme temperature option
(fluorosilicone elastomers)
Stainless Steel Construction
Standard
Extreme temperature option
(fluorosilicone elastomers)
48
Nameplate
49
Screw, self tapping (2 req'd)
63
Lithium grease (not furnished with the instrument)
64
Anti-seize compound (not furnished with the instrument)
8-4
Part Number
(7)
(21)
, and DVC6005f
(2)
(4 req'd)
(2)
(3 req'd)
(2,13)
(3 req'd)
38B9580X012
38B9580X032
38B9580X022
38B9580X042
(13)
Key
Description
65
Lubricant, silicone sealant (not furnished with the instrument)
(2)
154
Retaining Ring
(3 req'd)
(1)
237
Module Base Seal
Module Base
DVC6010f, DVC6020f, DVC6030f, DVC6005f
(see figures 8-2, 8-3, 8-4, 8-5, and 8-6)
(13)
2
Module Base
(13)
11
Drive Screw
(2 req'd)
(1)
12
O-ring
(13)
19
Label, Shield Assembly
(13)
61
Pipe Plug, hex socket
(3 req'd)
236
Screen, for single-acting direct units only
(13)
243
Flame Arrestor Assy
(3 req'd)
I/P Converter Assembly
DVC6010f, DVC6020f, DVC6030f, DVC6005f
(see figures 8-2, 8-3, 8-4, and 8-5)
23
Cap Screw, hex socket, SST
(1,10)
39*
O-ring
(10)
41
I/P Converter
(10,16)
169
Shroud
(1,10)
210*
Boot, nitrile
(2 req'd) (also see figure 7-4)
(1,8,10)
231*
Seal Screen
Relay
DVC6010f, DVC6020f, DVC6030f, DVC6005f
(see figures 8-2, 8-3, 8-4, and 8-5)
24*
Relay Assembly, (includes shroud, relay seal, mounting screws)
Standard
Single-acting direct (relay C)
Double-acting (relay A)
Single-acting reverse (relay B)
Low Bleed
Single-acting direct (relay C)
Double-acting (relay A)
Single-acting reverse (relay B)
Extreme Temperature option (fluorosilicone elastomers)
Standard Bleed
Single-acting direct (relay C)
Double-acting (relay A)
Single-acting reverse (relay B)
Low Bleed
Single-acting direct (relay C)
Double-acting (relay A)
Single-acting reverse (relay B)
*Recommended spare
1. Available in the Elastomer Spare Parts Kit
2. Available in the Small Hardware Spare Parts Kit
3. Available in the DVC6010f to DVC6020f Conversion Kit
7. Available in the Pipe-Away Bracket Kit
8. Available in the Seal Screen Kit
10. Available in the I/P Converter Kit
13. Available in the Spare Module Base Assembly Kit
14. Available in the Spare Housing Assembly Kit
16. Available in the Spare Shroud Kit
21. Available in the Pipestand/Wall Mounting Kit
Part Number
(13)
(2,16)
(4 req'd)
38B5786X132
38B5786X052
38B5786X092
38B5786X152
38B5786X072
38B5786X112
38B5786X142
38B5786X032
38B5786X102
38B5786X162
38B5786X082
38B5786X122
December 2009
