DVC6000f Digital Valve Controllers
Label
PARAMETER_NAME
Deviation High Priority
DV_HI_PRI
Deviation High Limit
DV_HI_LIM
Deviation Low Priority
DV_LO_PRI
Deviation Low Limit
DV_LO_LIM
High High Alarm
HI_HI_ALM
UNACKNOWLEDGED
4
ALARM_STATE
TIME_STAMP
SUBCODE
VALUE
High Alarm
HI_ALM
UNACKNOWLEDGED
ALARM_STATE
TIME_STAMP
SUBCODE
VALUE
Low Alarm
LO_ALM
UNACKNOWLEDGED
ALARM_STATE
TIME_STAMP
SUBCODE
VALUE
Low Low Alarm
LO_LO_ALM
UNACKNOWLEDGED
ALARM_STATE
TIME_STAMP
SUBCODE
VALUE
4-94
Table 4-31. PID Function Block System Parameters Definitions (Continued)
Index RO / Block
Number RW Mode
56 ALL 0 to 15
57 ALL PV_SCALE, or +INF
58 ALL 0 to 15
−INF, or −PV span to 0
59 ALL
60
0=Undefined
1=Acknowledged
60.1 RW N/A
2= Unacknowledged
0=Undefined
1=Clear reported
60.2 RO N/A 2=Clear not reported
3=Active reported
4=Active not reported
60.3 RO N/A
60.4 RO N/A
60.5 RO N/A
61
0=Undefined
61.1 RW N/A 1=Acknowledged
2= Unacknowledged
0=Undefined
1=Clear reported
2=Clear not reported
61.2 RO N/A
3=Active reported
4=Active not reported
61.3 RO N/A
61.4 RO N/A
61.5 RO N/A
62
0=Undefined
62.1 RW N/A 1=Acknowledged
2=
Unacknowledged
0=Undefined
1=Clear reported
2=Clear not reported
62.2 RO N/A
3=Active reported
4=Active not reported
62.3 RO N/A
62.4 RO N/A
62.5 RO N/A
63
0=Undefined
63.1 RW N/A 1=Acknowledged
2=
Unacknowledged
0=Undefined
1=Clear reported
63.2 RO N/A 2=Clear not reported
3=Active reported
4=Active not reported
63.3 RO N/A
63.4 RO N/A
63.5 RO N/A
Range Initial Value
Data Type: Unsigned8
0
The priority of the deviation high alarm.
Data Type: Float
+INF The setting for the alarm limit used to detect the
deviation high alarm condition.
Data Type: Unsigned8
0
The priority of the deviation low alarm.
Data Type: Float
−INF
The setting for the alarm limit use to detect the
deviation low alarm condition.
0=undefined
Data Type: DS-71
The HI HI alarm data, which includes a value of
the alarm, a timestamp of occurrence, and the
state of the alarm.
0=undefined
VALUE Data Type: Float
0
0
0
0=undefined
Data Type: DS-71
The HI alarm data, which includes a value of the
alarm, a timestamp of occurrence, and the state
of the alarm.
0=undefined
VALUE Data Type: Float
0
0
0
0=undefined
Data Type: DS-71
The LO alarm data, which includes a value of the
alarm, a timestamp of occurrence, and the state
of the alarm.
0=undefined
VALUE Data Type: Float
0
0
0
0=undefined
Data Type: DS-71
The LO LO alarm data, which includes a value of
the alarm, a timestamp of occurrence, and the
state of the alarm.
0=undefined
VALUE Data Type: Float
0
0
0
