Chapter 4 TL1 Reference
Commands

Retrieve Performance Monitoring

This command retrieves the performance monitoring data from the TimeSource
3600. This data includes MTIE, TDEV, PHASE1S, and PHASE1M. For current 24
hour data, MTIE, TDEV, and PHASE1S data are grouped every 15 minutes. In
addition, there are 7 daily summaries of MTIE, TDEV, and PHASE1M. Each value
type can be retrieved for both span inputs A and B.
MTIE data includes the following time intervals in seconds: 1, 4, 10, 40, 100, 300,
900, 1800, 3600, 7200, 14400, 28800, and 86400.
TDEV data includes the following time intervals in seconds: 1, 2, 4, 8, 16, 32, 64,
128, 256, 512, and 1024.
PHASE1S data includes 900 seconds of phase values.
PHASE1M data includes 60 minutes of phase values.
The command format is:
RTRV-PM-EQPT:[<tid>]:SPAN-a:<ctag>::<montype>
Parameter
SPAN-a
<montype>
<mondat>=x
<montm>=x
172 TimeSource 3600 User's Guide
,,,,,[<mondat>][<montm>];
Value
a = A E1 span A input
a = B E1 span B input
MTIE MTIE data reported
TDEV TDEV data reported
PHASE1S 1-second phase data reported
PHASE1M 1-minute phase data reported
x = 1 to 12 Monitor date, month of the year
x = 1 to 31 Monitor date, day of the month
x = 0 to 23 Monitor time, hour past midnight
x = 0 to 59 Monitor time, minutes past the hour
Description
097-72060-01 Revision J – June, 2007
