Chapter 4 TL1 Reference
Commands

Enter Equipment

This command puts optional inputs in service, and causes the selected input to be
monitored. Additionally, this command can cause an input to be ensembled. All
in-service inputs are monitored. The Delete Equipment command must be used to
take an input out of service. The command format is:
ENT-EQPT:[<tid>]:<aid>:<ctag>:::<spec_block>;
Aid
SPAN-a
OPT-a
(990-72060-04
systems only)
The parameters which can be entered in the <spec_block> are listed below. For any
specific <aid> entered in a command, only certain parameters are valid. For each
valid parameter, choose the appropriate value from the Value column. When
entering multiple parameters, separate the parameters with commas.
Aid
SPAN-a
ENSEMBLER=b
Example to set an input to be monitored, but not ensembled:
ENT-EQPT:[<tid>]:SPAN-A:<ctag>;
Example to set an input to be monitored and ensembled:
ENT-EQPT:[<tid>]:SPAN-A:<ctag>:::ENSEMBLER=ALW;
Response Format:
M
;
146 TimeSource 3600 User's Guide
Value
Item Addressed
a = A
E1 span A input
a = B
E1 span B input
a = 1
ESCIU port 1
a = 2
ESCIU port 2
Parameter
Value
b = ALW
b = INH
<sid> <date> <time>
<ctag> COMPLD
/*LINK:<link>,CMD:<command>*/
Description
Span is monitored and ensembled
Span is monitored, but not ensembled
097-72060-01 Revision J – June, 2007
