Mounting
bracket
Outdoor Lightning
Antenna
Suppressor
Antenna cable
Drip Loop
Grounding Cable to Outside Ground
Source
Figure 3-11. Wall Antenna Outdoor Lightning Suppressor Mounting

Installing the Shelf

Rack Mounting
The shelf is shipped with the ears positioned for ETSI 53.5 cm mounting as
illustrated inFigure
the rack rail for flush mounting
cm offset mounting
TimeSource 3600 Shelf for proper ventilation. Mount the shelf in the rack according
to standard company practices.
Note: Two screws may be used in both mounting ears if the holes in
the rack are spaced 4.45 cm apart.
097-72060-01 Revision J – June, 2007
Building exterior
3-12A. For 48 cm racks, the shelf can be positioned to the rear of
(Figure
(Figure 3-12C). Leave 1 RU (4.45 cm) of air space above the
Chapter 3 Installing the TimeSource 3600
Wall
Hole for cable
RG-316 Cable (10 feet)
060-00062-01
Building interior
3-12B) or to the front of the rack rail for 12.7
TimeSource 3600 User's Guide
Installing the Shelf
IF Converter
73
