Chapter 3 Installing the TimeSource 3600
Installing the Shelf
Table 3-5. COM2 Connector Pinouts
Pin
2 Transmit data
3 Receive data
4 Signal Ground
5 Data terminal ready
7 Clear to send
8 Request to send
Note: Pins not listed are reserved for future use.

Craft Port

To provide an RS-232 link for TL1 command access to the TimeSource 3600,
connect to the craft port at the female RJ-45 connector labeled Craft on the front
panel. A Craft-port-to-PC cable is supplied with the TimeSource 3600 for making
this connection. See
the connector pinouts.
Note: The Craft connector transmits data on pin 2, and receives data
on pin 3. Be sure the other equipment receives data from the
transmitting pin, and transmits data to the receiving pin.
92 TimeSource 3600 User's Guide
Signal Abbreviation
TXD
RXD
GND
DTR
CTS
RTS
Figure 3-14 for the location of the connector, and
Direction
From TimeSource 3600
To TimeSource 3600
—
From TimeSource 3600
To TimeSource 3600
From TimeSource 3600
Table 3-6
097-72060-01 Revision J – June, 2007
