For Mechanical Window Antenna Installation

Drill with bit of appropriate size and type to make pilot holes for the mounting
screws
2 screws of appropriate size and type to attach the foot of the mechanical chassis
to a window sill or wall near a window.
Screwdriver
Cable ties or other method of securing cable
GPS handheld receiver, personal computer with GPS location software, or other
method of determining latitude, longitude, and altitude
For Self-Adhesive Window Antenna Installation
Drill with bit of appropriate size and type to make pilot holes for the mounting
screws
4 screws of appropriate size and type to attach the IF converter to a wall or other
mounting surface.
Screwdriver
GPS handheld receiver, personal computer with GPS location software, or other
method of determining latitude, longitude, and altitude
For Wall Antenna Installation
Ladder, or safe method of reaching the antenna location on the exterior wall
Drill with bits of appropriate size and type to make pilot holes for the antenna
mounting bracket screws, and to make a hole through the wall for the antenna
cable
2 screws of appropriate size and type to attach the antenna mounting bracket to
an exterior wall.
Screwdriver
Electrically conductive antioxidant compound (Kopr-Shield or equivalent) to coat
exposed connections to prevent oxidation
Fire stopping material to seal the hole in the wall
GPS handheld receiver, personal computer with GPS location software, or other
method of determining latitude, longitude, and altitude
For Shelf Installation
A Phillips-head screwdriver for installing the TimeSource 3600 Shelf in a rack
Four screws to mount the shelf in a rack
097-72060-01 Revision J – June, 2007
Chapter 2 Engineering & Ordering
User-Supplied Tools and Materials
TimeSource 3600 User's Guide 55
