Chapter 1 Overview of the TimeSource 3600
Physical Description
to TimeSource 3600 Shelf
Figure 1-3. Mechanical Window Antenna

Self-Adhesive Window Antenna

The self-adhesive window antenna assembly
and two pieces of self-stick hook-and-loop fabric fasteners (Velcro brand or
equivalent). The hook-and-loop fabric attaches directly to a window. Coaxial cables
carry signals and power between the antenna and the IF converter, and between
the IF converter and the shelf.
Figure 1-4. Self-Adhesive Window Antenna
26 TimeSource 3600 User's Guide
Antenna
Coaxial Cable
Mounting Assembly
IF Converter
Coaxial Cable
(not included with
antenna assembly)
GPS WINDOW
ANTENNA
43 cm
(Figure 1-4) consists of the antenna
097-72060-01 Revision J – June, 2007
