Stop Bits
Flow Control
Connector Type
Connector Label
Connector Location
Electrical Interface
Pin that transmits data
Pin that receives data
Baud Rate
Data Bits
Parity Bit
Stop Bits
Flow Control
097-72060-01 Revision J – June, 2007
Port 2 (Continued)
1
2
None
Software (XON/XOFF)
Hardware (CTS/RTS)
Craft Port
RJ-45
Craft
Front panel
RS-232 (DTE equivalent)
2
3
1200 b/s
2400 b/s
4800 b/s
9600 b/s (factory default)
19.2 kb/s
38.4 kb/s
57.6 kb/s
115 kb/s
8
None
Even
Odd
1
2
None
Chapter 6 Specifications
Communication and Ethernet Ports
