Chapter 2 Engineering & Ordering
User-Supplied Tools and Materials
– Mounting bracket (070-00300-03)
– Surge protector (143-00018-02)
– RG316 cable, 3 m, SMA(m)-SMA(m) (060-00062-01)
User-Supplied Tools and Materials
Ensure that the user-supplied tools and materials listed below are on hand for
installation, as applicable.
For Roof Antenna Installation
2.5 cm diameter galvanized metal pipe, used as a mast to mount the antenna.
Mast should be long enough to position the antenna above any metal object on
the roof.
Screws to attach the lightning suppressor mounting plate.
Plumb line or bubble level.
Nonmetallic junction box for lightning suppressor (optional if lightning suppressor
mounted indoors).
2. 5 cm diameter PVC pipe as conduit for outdoor cables.
PVC fittings appropriate to the installation and cable route.
Appropriate tools and materials for cutting and shaping PVC pipe.
PVC glue
4.114 mm (6 AWG) ground wire.
Spade lugs for 6 AWG ground wire.
Crimp tool for 6 AWG spade lugs.
Hardware to attach the ground wire to a valid earth ground.
Fire-stopping material to seal conduit hole in roof or wall.
Electrically conductive antioxidant compound (Kopr-Shield or equivalent) to coat
exposed connections to prevent oxidation.
Tool to cut cable, if installation requires custom lengths of cable.
Phillips Screwdriver
Wrench
1/4 inch hex Allen wrench
54
TimeSource 3600 User's Guide
097-72060-01 Revision J – June, 2007
