Chapter 6 Specifications

Office Alarms

ESCIU Ports (990-72060-04 System Only) (Continued)
Wire-wrapSPAN 1
SPAN 2
BNCSPAN 1
SPAN 2
Connector Location
Electrical Interface
Ports
Maximum cable length
CSU Functionality
Output During LOS Alarm
Input jitter tolerance
Input wander tolerance
Office Alarms
Connection
Type
Contact Rating
212 TimeSource 3600 User's Guide
RTN1 (T, R, S) (2 sets of pins)
IN (T, R, S)
OUT (T, R, S)
RTN2 (T, R, S) (2 sets of pins)
IN (T, R, S)
OUT (T, R, S)
RTN1 OUT
RTN1 IN
OUT
IN
RTN2 OUT
RTN2 IN
OUT
IN
Connector panel output module
E1 (ITU G.703 and G.704)
Two bidirectional:
(E1 signals are buffered and retimed in
forward direction, passed through in
reverse direction)
150 m (either direction, to or from DDF)
None
AIS
LOS
ITU G.823 (1993) requirements
±125 μs
Connector Panel Contacts
Wire-wrap pins
Dry contact
1 A @ 30 V dc
0.5 A @ 60 V dc
0.5 A @ 125 V ac
097-72060-01 Revision J – June, 2007
