Width
Depth
Weight
Type
Cable Length
Dimensions
Height
Width
Depth
Weight

Communication and Ethernet Ports

Connector Type
Connector Label
Connector Location
Electrical Interface
Pin that transmits data
Pin that receives data
Baud Rate
097-72060-01 Revision J – June, 2007
Wall Antenna (Continued)
37 mm
46 mm
35 g
Self-Adhesive Window Antenna
Patch antenna and proprietary IF interface
Maximum 305 m from antenna to shelf
7.6 cm
10.2 cm
4.3 cm
170 g
Port 1
25-pin, female D connector
COM1
Connector panel
RS-232 (DTE equivalent)
2
3
1200 b/s
2400 b/s
4800 b/s
9600 b/s (factory default)
19.2 kb/s
38.4 kb/s
57.6 kb/s
Chapter 6 Specifications
Communication and Ethernet Ports
TimeSource 3600 User's Guide 199
