Chapter 6 Specifications
Output Ports
Additional E1 Outputs (990-72060-02 System Only) (Continued)
BNC
Connector Location
Impedance
Bit Rate
Frequency Accuracy
GPS Holdover Stability
Format
Line Code
Amplitude
Framing
Output During Alarms
SSM
State
208 TimeSource 3600 User's Guide
OUT1
OUT2
OUT3
OUT4
OUT5
OUT6
OUT7
OUT8
Connector panel output module
Ω Ω
120 balanced or 75
2.048 Mb/s
12
–
1 x 10
11
–
1 x 10 for 72 h (0 °C to +50 °C
after one week of steady-state operation
10
–
1 x 10 for 30 days after one week of
steady-state operation
Framed all 1s
HDB3
3.0 V nominal terminated with 120
balanced
2.37 V nominal terminated with 75
unbalanced
CAS
CAS4
CCS
CCS4
AIS
Squelch
SSM
Enable
Disable
