TimeSource 3100
GPS Primary Reference Source
097-72020-01
Issue 9: November 2003

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TimeSource 3100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Symmetricom TimeSource 3100

Summary of Contents for Symmetricom TimeSource 3100

  • Page 1 TimeSource 3100 GPS Primary Reference Source 097-72020-01 Issue 9: November 2003...
  • Page 2 Symmetricom, Inc. 2300 Orchard Parkway San Jose, CA 95131-1017 http://www.symmetricom.com Copyright © 1999-2002 Symmetricom, Inc. All rights reserved. Printed in U.S.A. All product names, service marks, trademarks, and registered trademarks used in this document are the property of their respective owners.
  • Page 3 Acronyms and Abbreviations alarm indication signal digital transmission (2.048 Mb/s) electrostatic discharge extended superframe Global Positioning System loss of signal MDEV mean time deviation pulse per second primary reference source remote oscillator rack unit (4.45 cm) synchronization status messaging digital transmission (1.544 Mb/s) TDEV time deviation time of day...
  • Page 4 What’s New in This Manual This issue of the TimeSource 3100 user manual has the following changes from the previous issue: • Added “Startup”, “Bridging/Holdover Behavior” and “Time Figure of Merit” sections to Chapter 1. • Removed TimeScan Craft connection key (020-46700-001) from system equipment lists in Chapter 2.

  • Page 5: Table Of Contents

    Site Survey ........... . . 30 TimeSource 3100...
  • Page 6 Module for ESCIU Ports ........70 Cutover Procedures for Out-of-Service Equipment ....71 TimeSource 3100 Contents...
  • Page 7 Retrieve Condition All ......... 154 TimeSource 3100...
  • Page 8 Standard ........... . 216 TimeSource 3100...
  • Page 9 Shelf Environmental ..........226 TimeSource 3100...

  • Page 10: Contents 097-72020-01 Issue 9: November

    TimeSource 3100 Contents 097-72020-01 Issue 9: November 2003...

  • Page 11: Chapter 1 Description

    Chapter 1 Description This chapter provides an overview of the global positioning system, and a physical and functional description.

  • Page 12: Overview

    The synchronization timing is traceable to the GPS, which provides the highest level of synchronization for telephony networks. The TimeSource 3100 with its GPS input is a stand-alone office PRS. With the optional inputs ensembled, overall system performance is improved, and holdover is extended if GPS signals become disrupted.

  • Page 13: Global Positioning System

    This configuration assures that a minimum of 4 satellites, and as many as 12, are in view anywhere in the world at all times. The TimeSource 3100 tracks all satellites within its field of view. The performance of each tracked satellite is observed and compared to the others, and available for use in the timing solution.

  • Page 14: Physical Description

    Physical Description The TimeSource 3100 consists of a shelf, a plug-in card, an antenna, cables, hardware, and software. Optional system configurations include eight additional E1 or analog outputs, two E1 synchronous clock insertion unit (ESCIU) ports, four IRIG-B TOD timing outputs, or eight mixed E1/T1 outputs.
  • Page 15 Figure 1. Shelf TimeSource 3100 Description 097-72020-01 Issue 9: November 2003...

  • Page 16: Roof Antenna

    The antenna (Figure 2) is encased in weather-resistant plastic housing for outdoor installation, usually on a roof. A single coaxial cable carries signals and power between the antenna and the shelf. Figure 2. Antenna 31.4 cm 7.6 cm TimeSource 3100 Description 097-72020-01 Issue 9: November 2003...

  • Page 17: Functional Description

    Functional Description Overview Figure 3 shows the main functions of the TimeSource 3100. The center of the TimeSource 3100 is the Ensemble Timing Generator, which uses the BesTime algorithm to analyze the phase and frequency relationships, individually and collectively, of the timing sources. Each type of timing source has a particular characteristic that gives it an advantage over other sources, as listed in Table A.
  • Page 18 Figure 3. Block Diagram TimeSource 3100 Description 097-72020-01 Issue 9: November 2003...

  • Page 19: Antenna

    A digitally controlled, oven-controlled crystal oscillator (OCXO) develops a highly stable local oscillator signal, independent of factors that exist outside the shelf. This signal is sent to the BesTime Ensemble Timing Generator. TimeSource 3100 Description 097-72020-01 Issue 9: November 2003...

  • Page 20: Clock Extractors

    Use of the Simple Network Time Protocol (SNTP) feature requires activation with a password. Activation is accomplished through receipt of a Network Time Protocol Activation Certificate from Symmetricom. This certificate contains the unit purchase order number, unit model number, unit activation date, unit serial number, and unit activation key.

  • Page 21: E1 Or Analog Outputs

    IRIG-B. 1 PPS Output The BesTime Ensemble Timing Generator provides the timing for the 1 pulse-per-second timing signal available at the 1 PPS connector, which can be used for application-specific requirements. TimeSource 3100 Description 097-72020-01 Issue 9: November 2003...

  • Page 22: 10 Mhz Output

    The microprocessor delivers alarms to normally open dry-contact type connections. Alarms are also indicated by the front-panel status lamps. Communications Ports Three RS-232 serial communications ports carry TL1 commands, responses, and autonomous messages between the TimeSource 3100 and an external terminal. TimeSource 3100 Description 097-72020-01 Issue 9: November 2003...

  • Page 23: Ethernet

    Manager, sends autonomous messages, and closes the connection when finished. Passthrough The Passthrough feature of the TimeSource 3100 allows the unit to front a DCD product to provide one management interface for a user site. Passthrough allows a user to do the following: •...

  • Page 24: Alarm Programmability

    Figure 5. TimeSource 3100 Passthrough Function DCDPASSTHRU Straight cable User port (any port) DCD-5X TS-3100 DCDUSERPORT COM 1, 2, 3 IP:5001-5004 COM1 or 2 (COM-1 is COM 1, 2, or 3 DB-25 and COM-2 is DB-9) Alarm Programmability New releases of TimeSource (1.05.03 and higher) allows the user to provision the alarm escalation parameters that were hardcoded in the previous releases of TS3100.hex.

  • Page 25: Bridging/Holdover Behavior

    This ensures that intermittent conditions are not flagged unnecessarily. During the normal working of the TimeSource 3100, it is a very common occurrence that the GPS satellites may not be visible during certain parts of the day, depending on the installation of the antenna.

  • Page 26: Time Figure Of Merit

    In addition, rooftop antennas are mounted vertically and all signals below the horizon are obvious multipath interference and can be masked out of the system. With 4 TimeSource 3100 Description 097-72020-01 Issue 9: November 2003...
  • Page 27 • Maturing foliage or seasonal foliage changes • Installation of new transmitters nearby (i.e. wireless base station) • New building construction • Variations in the day-to-day temperature of the CO TimeSource 3100 Description 097-72020-01 Issue 9: November 2003...
  • Page 28 TimeSource 3100 Description 097-72020-01 Issue 9: November 2003...

  • Page 29: Chapter 2 Engineering & Ordering

    Chapter Engineering & Ordering This chapter provides information to assist in planning the installation and ordering a system appropriate for a specific site.

  • Page 30: Site Survey

    Determine the two separate –48 V power sources for the shelf. If only one – 48 V power source is available, it must be cabled to both TimeSource 3100 power inputs. End of Procedure...

  • Page 31: Lightning Suppressor Guidelines

    • Treat all exposed connections with an electrically conductive anti-corrosion compound (Kopr-Shield or equivalent). Warning: Avoid small-radius turns and unnecessary turns. TimeSource 3100 Engineering and Ordering 097-72020-01 Issue 9: November 2003...

  • Page 32: Antenna Location Guidelines

    Signals closer to the horizon are often subject to multipath effects, which degrade the timing solution. The TimeSource 3100 can be set to ignore, or mask, all signals from the horizon to a chosen angle of elevation (mask angle). (See Figure 6.) Figure 6.
  • Page 33 Place the antenna high enough that the roof structure and tree are below the mask angle, and the water tower does not block a large portion of the sky. TimeSource 3100 Engineering and Ordering 097-72020-01 Issue 9: November 2003...
  • Page 34 (to avoid danger to personnel or multipath effects). Figure 8. Sample Rooftop Antenna Mount Note: This is an example only. Not all parts are available from Symmetricom. TimeSource 3100 Engineering and Ordering...

  • Page 35: Earth Ground Location Guidelines

    4.6 m of the valid earth ground. TimeSource 3100 Engineering and Ordering 097-72020-01 Issue 9: November 2003...

  • Page 36: Antenna Cable Choices

    Two cables are required: one to connect the antenna to the lightning suppressor, and another to connect the lightning suppressor to the TimeSource 3100 Shelf. Symmetricom offers RG-59/U plenum-rated coaxial cable (0.812 mm [20 AWG], 75 ohm coaxial) with male TNC connectors attached, in the following lengths: •...

  • Page 37: Remote Oscillator Cabling

    DCD-419 (Rev. D or later), or SMB-to-BNC connectors for connecting to the DCD-419. The isolation module is used to reduce potential noise coupling, and match impedances in the cables between the DCD master shelf and TimeSource 3100. It also converts the 5 MHz output from a square wave to a sine wave.

  • Page 38: Irig-B Tod (990-72020-05 Systems Only)

    IRIG-B TOD (990-72020-05 Systems Only) If using the IRIG-B TOD outputs (990-72020-05 TimeSource 3100 System), right-angle BNC connectors are provided to prevent small radius turns in the IRIG-B TOD cables. The right-angle BNC connectors may be attached to the IRIG-B BNC adapter (also provided) BNC connectors, to direct the cables from the shelf as desired.

  • Page 39: Rj-422-To-Rj-232 Tod Converter

    DB-25 connector, a TOD converter, and two screws. Install the converter anywhere (for example, on unused space on a rack) within 305 cable meters of the TimeSource 3100 shelf, and within 15 cable meters of the device receiving the time code.

  • Page 40: Shelf Considerations

    Shelf Considerations The TimeSource 3100 Shelf can be mounted in an ETSI 53.5 cm rack or a 48 cm rack. The shelf is shipped with supplied mounting ears positioned for flush mounting on an ETSI 53.5 cm rack. Attach the mounting ears (Figure 9) to the appropriate positions on the sides of the shelf for flush mounting or 12.7 cm offset mounting.

  • Page 41: Systems

    Systems The TimeSource 3100 Systems available are listed below. Standard System (Two E1 or 2.048 MHz Outputs) This system (990-72020-01) includes: • TimeSource 3100 Shelf (090-72000-11) • TimeSource 3100 card (090-72020-01) • Antenna (090-72010-97) • Antenna mounting kit (093-00001-01) •...

  • Page 42: With Eight Additional E1 Or 2.048 Mhz Outputs

    With Eight Additional E1 or 2.048 MHz Outputs This system (990-72020-02) includes: • TimeSource 3100 Shelf (090-72000-11) • TimeSource 3100 card with expansion E1 or 2.048 MHz outputs (090-72020-02) • Antenna (090-72010-97) • Antenna mounting kit (093-00001-01) • Hardware kit (093-72020-97) includes:...

  • Page 43: With Eight Additional Mixed E1/T1Outputs

    With Eight Additional Mixed E1/T1Outputs This system (990-72020-06) includes: • TimeSource 3100 Shelf (090-72000-11) • TimeSource 3100 card with mixed E1/T1 outputs (090-72020-06) • Antenna (090-72010-97) • Antenna mounting kit (093-00001-01) • Hardware kit (093-72020-97) includes: Lightning suppressor (143-00018-01) Lightning suppressor mounting bracket (070-00300-02) Craft port-to-PC communications cable (060-00067-01) •...

  • Page 44: With Two E1 Synchronization Insertion (Esciu) Ports

    With Two E1 Synchronization Insertion (ESCIU) Ports This system (990-72020-04) includes: • TimeSource 3100 Shelf (090-72000-11) • TimeSource 3100 card with ESCIU ports (090-72020-04) • Antenna (090-72010-97) • Antenna mounting kit (093-00001-01) • Hardware kit (093-72020-97) includes: Lightning suppressor (143-00018-01)

  • Page 45: With Four Irig-B Tod Outputs

    With Four IRIG-B TOD Outputs This system (990-72020-05) includes: • TimeSource 3100 Shelf (090-72000-11) • TimeSource 3100 card with IRIG-B TOD outputs (090-72020-05) • Antenna (090-72010-97) • Antenna mounting kit (093-00001-01) • Hardware kit (093-72020-97) includes: Lightning suppressor (143-00018-01) Lightning suppressor mounting bracket (070-00300-02) Craft port-to-PC communications cable (060-00067-01) •...

  • Page 46: User-Supplied Tools And Materials

    Tool to cut cable, if installation requires custom lengths of cable. For Shelf Installation Ensure that a Phillips-head screwdriver is on hand for installing the TimeSource 3100 Shelf in a rack and four (4) screws to mount the shelf in the rack.

  • Page 47: Outputs, Power, And Miscellaneous

    4.115 mm (6 AWG) ground wire • 1.47 mm (16 AWG) green insulated ground wire • 1.47 mm (16 AWG) red insulated wire • 1.47 mm (16 AWG) black insulated wire • E1 cable TimeSource 3100 Engineering and Ordering 097-72020-01 Issue 9: November 2003...
  • Page 48 TimeSource 3100 Engineering and Ordering 097-72020-01 Issue 9: November 2003...

  • Page 49: Chapter 3 Installation

    Installation This chapter provides the steps required for installation and power-up. Chapter...

  • Page 50: Unpacking

    Unpacking Install the TimeSource 3100, using steps in the order given in this chapter. If any difficulties are encountered during the installation process, contact Symmetricom's Customer Technical Assistance Center (CTAC). Refer to the Technical Assistance section of the Troubleshooting chapter for telephone numbers.

  • Page 51: Antenna

    To install the antenna, refer to Figure 10, and perform Procedure B. Warning: Ensure that the lightning suppressor is placed away from electrical devices or cabling that may induce arcing. Figure 10. Antenna-to-Shelf Cabling TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 52 Leave the V-bolts loose enough to allow for final adjustments. • If mounting the bracket to a wood post, use the provided two self-tapping screws in two diagonally positioned mounting bracket slots, and attach to the post. TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 53 Note: A junction box must have inside dimensions of 7 cm by 7 cm by 4 cm to hold the mounting plate and attached components. TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 54 Connect a cable to the lightning suppressor, route the cable through the conduit into the building, and route the cable through the building to the TimeSource 3100 Shelf location. If the lightning suppressor was not mounted directly to a valid earth ground, crimp a length of 4.115 mm (6 AWG) round cable to the two-hole terminal, slide the terminal over two of...
  • Page 55 Procedure B. Antenna Mounting and Cable Connection (cont’d) Step Procedure Check all connections for tightness to prevent arcing and intermittent operation. Coat all exposed connectors with an electrically conductive antioxidant compound (e.g. Kopr-Shield spray). End of Procedure TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...

  • Page 56: Shelf

    Align the three spring-loaded screws on the module with the threaded holes on the panel. Use a medium flat-blade screwdriver to lock each screw in place. Torque the screws evenly to prevent skewing the module. Figure 11. Options I/O Connector TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...

  • Page 57: Rack Mounting

    (Figure 12B) or to the front of the rack rail for 12.7 cm offset mounting (Figure 12C). Position the mounting ears, as shown in Figure 12. Mount the shelf in the rack according to standard company practices. Figure 12. Rack Mounting Options TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...

  • Page 58: Cabling

    To access the shelf connector panel, remove its cover. Figure 13 shows the connectors on the front panel and connector panel. All connectors can be located using these illustrations. TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 59 8 E1 outputs (BNC or Expansion Bus wire-wrap) or (Reserved for 4 IRIG-B TOD outputs (BNC) or antenna future use) input 2 ESCIU ports (BNC or wire-wrap) or 8 mixed E1/T1 outputs (wire-wrap) TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...

  • Page 60: Frame Ground

    Note: When soldering, use a 25 watt soldering iron to ensure the frame ground rod is heated sufficiently to prevent a cold solder connection TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...

  • Page 61: Power

    Caution: Do not apply power to the TimeSource 3100 Shelf before instructed in this procedure. Before connecting the power cables to the TimeSource 3100, ensure the fuses are removed from the fuse panel that supplies power to the power cables.

  • Page 62: E1 Or Analog Synchronization Outputs

    Because the El output circuits do not provide lightning protection, do not connect the El output line directly to a point outside the building. Failure to observe this warning may result in equipment damage. Figure 15. E1 or Analog Output Wire-Wrap Connections TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...

  • Page 63: Pps Output

    IN A and SPAN IN B. If using the wire-wrap pins, connect the tip wire to the pin labeled T, the ring wire to the pin labeled R, and the shield (if connected at the TimeSource 3100) to the pin labeled S. See Figure 13 for the location of the connectors and pins, and Figure 16 for the wire-wrap connections.

  • Page 64: Remote Oscillator Inputs

    For the connection between the Time Source 3100 Shelf and the isolation module, use the provided two 1.83 meter lengths of 50 ohm coax cables. If the TimeSource 3100 Shelf is not collocated with the DCD Shelf, and longer cables are required, these must not exceed 15 meters, and are to be user-supplied.
  • Page 65 Table B. DCD Connections to the TimeSource 3100 From DCD Shelf To TimeSource 3100 Shelf Type Connector Label Connector DCD-ST2 5 MHZ OUTPUT A REM OSC A 5 MHZ OUTPUT B REM OSC B DCD-419 NOT LABELED REM OSC A...
  • Page 66 Figure 17. DCD Shelf, Isolation Module, and TimeSource 3100 Connections DCD Shelf without Isolation Module If an isolation module is not required, use two 50 ohm coax cables to make the connections to the DCD Shelf. Cables must not exceed 15 meters, and must be purchased separately or are to be user-supplied.

  • Page 67: Module For Additional E1 Or Analog Outputs

    Connect the optional eight E1 or analog outputs with the wire-wrap or BNC output module. See Figure 13 for the connector location, and Figure 18 for the connections. Figure 18. Eight E1 or Analog Output Connections TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...

  • Page 68: Module For Mixed E1/T1 Outputs

    Connect the optional eight mixed El/T1 outputs with the wire-wrap output module. See Figure 13 for the connector location, and Figure 19 for the connections. Figure 19. Eight Mixed E1/T1 Output Connections TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...

  • Page 69: Module For Irig-B Tod Outputs

    Connect the four optional IRIG-B TOD outputs with the IRIG-B output module. See Figure 13 for the connector location, and Figure 20 for the connections. Figure 20. IRIG-B TOD Output Connections Note: Outputs 5, 6, 7, and 8 are not used TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...

  • Page 70: Module For Esciu Ports

    G.703 paragraph 6 specifications. A bypass relay directs the E1 traffic around the ESCIU circuits to maintain continuity on the spans if a fault occurs. Figure 21. Connector Layout of ESCIU Modules TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...

  • Page 71: Cutover Procedures For Out-Of-Service Equipment

    Verify that there are no alarms on the NEs on the E1 system. If there are alarms, recheck the new cabling between the NEs and the ESCIU module. Restore (turn up) the traffic trunks to service. TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...

  • Page 72: Timesource

    Figure 22. ESCIU Cutover without Jacks (Out-of-Service) TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...

  • Page 73: Cutover Procedures For In-Service Equipment

    IN jack and the termination plugs in the OUT jack. Recheck the cross- connect wiring just installed, and repeat Step 5. Remove the remaining patch cords from the NE MON jack. TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 74 Figure 23. ESCIU Cutover with Jacks (In-Service) TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...

  • Page 75: Time Of Day Output

    1 pps B TOD PPS – From TimeSource 3100 12 V power source TOD P12V — Receive data B TOD RXD To TimeSource 3100 – Receive data A TOD RXD To TimeSource 3100 Circuit ground TOD GND — Transmit data A...
  • Page 76 1. Due to distance constraints, the converter must be placed no more than 305 m from the TimeSource 3100 Shelf, and no more than 15 m from the device receiving the time code. 2. The converter dimensions are 7.5 cm by 3.8 cm by 2.5 cm.
  • Page 77 Figure 25. RJ-45 to DB-25 TOD Converter Connections Table D. Converter DB-25 Connector Pinouts Signal Frame ground Data output (RS-232) 1 pps (RS-232) Signal ground Note: Pins not listed are reserved for future use. TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...

  • Page 78: Ethernet

    Direction Transmit data + TXD + From TimeSource 3100 Transmit data – TXD – From TimeSource 3100 Receive data + RXD + To TimeSource 3100 — — — — — — Receive data – RXD – To TimeSource 3100 —...

  • Page 79: Communication Port 1

    Communication Port 1 To provide an RS-232 link for TL1 command access to the TimeSource 3100, connect to port 1 at the female 25-pin D connector labeled COM 1. See Figure 13 for the location of the connector. See Table F for the connector pinouts.

  • Page 80: Communication Port 2

    Communication Port 2 To provide an RS-232 link for TL1 command access to the TimeSource 3100, connect to port 2 at the female 9-pin D connector labeled COM2. See Figure 13 for the location of the connector, and Table G for the connector pinouts.

  • Page 81: Alarms Output

    Alarms Output Connect the TimeSource 3100 alarms to the office alarm panel at the critical (CR), major (MJ), and minor (MN) wire-wrap pins. See Figure 13 for the location of the alarm pins, and Figure 26 for the connections. Connect at the upper group of pins (AUD) for audible alarms and at the lower group of pins (VIS) for visible alarms.

  • Page 82: Craft Port

    Craft Port To provide an RS-232 link for TL1 command access to the TimeSource 3100, connect to the craft port at the female RJ-45 connector labeled Craft on the front panel. A Craft-port-to-PC cable is supplied with the TimeSource 3100 for making this connection. See Figure 13 for the location of the connector, and Table H for the connector pinouts.

  • Page 83: Power-Up

    Attach a grounding wrist strap to the wrist, and plug the other end into the ground jack at the upper-right corner of the front of the plug-in card. Pull out the latching levers at each end of the front panel of the TimeSource 3100 card so that the levers are pointing directly out from the front panel.
  • Page 84 Unplug and remove the grounding wrist strap. Install the battery source fuse in the rack fuse bay that supplies power to the TimeSource 3100. The TimeSource 3100 enters its warm-up mode when power is applied. During the warm-up period, the following conditions exist: •...
  • Page 85 = framing format (b = CAS, CAS4, CCS, or CCS4, or NONE for analog) c = E1 output during alarm (c = AIS, SQUELCH, or SSM) (for SSM, framing format must be CAS4 or CCS4) TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 86 COM1, COM2, or the CRAFT port to set the IP address, subnetwork mask, and gateway address for the current TimeSource 3100 unit, as required for proper operation in the managed element network. (These parameters affect all Ethernet ports. The Ethernet port should be closed and all users logged off before issuing this command.)
  • Page 87 Procedure E. Power-Up (cont’d) Step Procedure Ports 5001, 5002, 5003 and 5004 on the TimeSource 3100 are used as though they were serial TL1 communication ports. The following values are set at the factory and appear at reset: COMPRI=ALW1 (normal communication, including autonomous messages)
  • Page 88 Element Manager, skip to Step 28. Use the Edit Equipment command to set the IP address and port address of the Element Manager. Port 5550 connects to this address when the TimeSource 3100 develops a TL1 autonomous message, sends any messages, and closes the connection. An alternate Element Manager may be set up in case port 5550 cannot make a connection to the primary Element Manager.
  • Page 89 Directs this command to ESCIU span 1 (a=1) or span 2 (a=2) b= If LOS is detected on the incoming span, the ESCIU passes AIS downstream (b=AIS) or passes the LOS downstream (b=PASSTHRU) TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 90 This may be useful when testing, troubleshooting, or in installations where the outputs generated by the TimeSource 3100 may be better than the alternative (for example, offices without additional holdover clocks in a distribution shelf).

  • Page 91: Timewizard

    TimeWizard The TimeWizard Software Installation application was created to facilitate installing software upgrades for the TimeSource 3100. Procedure F shows how to install the TimeWizard application and how to use TimeWizard to download software upgrades. Procedure F. TimeWizard Installation and Operation...
  • Page 92 “TS3000!!” appear in the Login Information area of the screen. If the user name or password of the TimeSource have been changed, enter the proper user name or password, otherwise, continue with the next step. TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 93 In most cases, it is desirable to proceed with the Use High Speed (115K baud) check-box selected. In certain instances, as when the PC’s communications port does not support a 115K baud rate, de-select the Use High Speed (115K baud) check-box before proceeding. TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 94 The versions of the GPS.hex and TS3000.hex firmware that are currently installed in the TimeSource are shown in the GPS.hex Ver and TS3000.hex Ver fields. Current satellite information is shown in the GPS Status field. TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 95 After TimeWizard verifies the firmware version, select the Download GPS.hex check-box, then click the Next>> button to start the firmware download operation. TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 96 Cancel button in the Download Progress dialog box. 2. If the download fails for any reason, a screen appears with instructions to contact Symmetricom. If this happens, exit the application, check the cable connections, and restart TimeWizard. After the Download Progress dialog box closes, continue to monitor the messages reported in the Commands area of the screen.
  • Page 97 Cancel button in the Download Progress dialog box. 2. If the download fails for any reason, a screen appears with instructions to contact Symmetricom. If this happens, exit the application, check the cable connections, and restart TimeWizard. TimeSource 3100...
  • Page 98 TimeSource reboots so that it can use the newly installed firmware. Upon rebooting, the system’s output might enter the degraded region of the PRS mask for up to one hour. After the screen automatically advances, continue with the next step. TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 99 The “Status Information” screen appears as follows: Verify that GPS.hex Ver and TS3000.hex Ver fields show that the correct versions of the GPS.hex and TS3000.hex firmware are now installed, then click the Next>> button. TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 100 This screen allows the parameters for GPS and Holdover alarm conditions to be modified. If you do not want to modify any of the alarm parameters, click the Next>> button and continue with Step 21. Otherwise, continue with the next step. TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 101 Severity 2The severity of the alarm after it has been escalated. Service Affecting 2The service affecting status of the alarm condition after the alarm has been escalated. When you are finished modifying the alarm parameters, click the Next>> button. TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 102 If the settings are correct, click the Next>> button to continue. If the settings are not correct, click the <<Back button to return to the “Set the Alarm Parameters” screen, and correct the settings. TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 103 If you do not wish to save the log file, ensure that the Save Log File to check-box is not selected, then click the Exit button to complete the TimeWizard firmware installation procedure. To save the log file, continue with the next step. TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 104 File Name field, then click the Save button to save the log file. Click the Exit button to complete the TimeWizard firmware installation procedure. End of Procedure TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...

  • Page 105: Factory-Set Values

    BYPASS=ALW (990-72020-04 systems only) TS3100 HOLDOVER TIME=24-0 ALARM SEV1=EV SEV2=MJ SAFF1=NSA SAFF2=SA TS3100 GPS TIME=3-0 ALARM SEV1=EV SEV2=MN SAFF1=NSA SAFF2=NSA ANTCBLDLY=0 ANTELEVMASK=10 RO-A, RO-B ENSEMBLER=INH MONITOR=INH SPAN-A, SPAN-B ENSEMBLER=INH MONITOR=INHSSM=INH SSM=INH SIGNAL=DIGITAL SSMCHANNEL=4 TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 106 SAFF2=NSA SPAN-A, SPAN-B TIME=24-0 ERROR ALARM SEV1=EV SEV2=MN SAFF1=NSA SAFF2=NSA RO-A, RO-B LOS TIME=24-0 ALARM SEV1=EV SEV2=MN SAFF1=NSA SAFF2=NSA RO-A, RO-B TIME=24-0 ERROR ALARM SEV1=EV SEV2=MN SAFF1=NSA SAFF2=NSA E1-A, E1-B FRAMING=CAS4 ALMOUT=AIS TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 107 BAUD=9600 COM-2, MONMSG=INH COM-3 KEEPALIVE=0 ENDOFTEXT=00 ECHO=ALW COMPRI=ALW1 AUTOLOGOFF=20 HWCONTROL=INH SWCONTROL=INH PARITY=NONE STOP=1 COM-5001, MONMSG=INH COM-5002, KEEPALIVE=0 COM-5003, ENDOWTEXT=00 COM-5004 ECHO=ALW COMPRI=INH AUTOLOGOFF=20 SWCONTROL=INH COM-5551 MONMSG=INH KEEPALIVE=0 ENDOFTEXT=00 ECHO=INH COMPRI=INH AUTOLOGOFF=20 SWCONTROL=INH TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...
  • Page 108 TimeSource 3100 Installation 097-72020-01 Issue 9: November 2003...

  • Page 109: Chapter 4 Tl1 Reference

    TL1 Reference This chapter provides information for using the TL1 language. Chapter 4...

  • Page 110: Conventions

    /* */ encloses comments for humans encloses a TL1 named variable \" "\ encloses a description of a condition indicates the previous line in a response may be repeated as required TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 111: Command Format

    Entering a semicolon at the end of the command indicates that the command statement is completed to the interpreter, and executes the command. Figure 27. Command Format TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 112: Response Format

    ^^^<sid>^<date>^<time> M^^<ctag>^COMPLD ^^^/*LINK:,link>,CMD:<command>*/ Note: If the command was a query, additional information would be displayed before the semicolon. Figure 29. Deny Response Format ^^^<sid>^<date>^<time> M^^<ctag>^DENY ^^<errcode> ^^^/* <error message> */ ^^^/*LINK:,link>,CMD:<command>*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 113: Parameters

    Current date in the 8-digit form: yyyy-mm-dd (command) or yyyy:mm:dd (response or message), where yyyy is the year, mm is the month (01-12), and dd is the day of the month (01-31). For example, May 3, 2000 is 2000-05-03. TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 114 Occurrence time in the 6-digit form: hh-mm-ss (command) or hh:mm:ss (response or message), where hh is hours (00 to 23), mm is minutes (00 to 59), and ss is seconds (00 to 59). For example, 2:34 pm is14:34:00. TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 115 Private identifier, factory-set to “TS3000!!”. It is the initial password for the TELECOM <uid>. Passwords are encrypted when stored in the TimeSource 3100, and are never transmitted from the shelf. The pid contains a case-insensitive string of 8 to 10 ASCII...

  • Page 116: Autonomous Messages

    Report Event: reports events that are not alarms, or that have not yet become alarms Autonomous messages are listed on the following pages. After the message name, a definition of the message is given. TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 117: Report Alarm

    This autonomous message appears when an alarm is raised, and appears again when the alarm is cleared. Message: ^^^<sid> <date> <time> M^^<almcde> <atag> REPT ALM EQPT <modifier> ^^^"<aid>:<ntfcncde>,<condtype>,<srveff>, <ocrdat>,<ocrtm>,,,:\"<conddescr>\ "[:<dgntype>]" Note: Refer to Table J for parameter definitions. TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 118: Report Event

    An event is a state of the TimeSource 3100 that does not cause an alarm. Message: ^^^<sid> <date> <time> M^^<atag> REPT EVT EQPT <modifier> ^^^"<aid>:<condtype>,<condeff>,<ocrdat>,<ocrtm> ,,,,:\"<conddescr>\"[:<dgntype>]" Note: Refer to Table J for parameter definitions. TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 119: Tasks/Commands

    Display current system alarms and events Retrieve Condition All Display current alarms and events for specific Retrieve Condition equipment Equipment Display parameter settings of equipment Retrieve Equipment Display GPS status information Retrieve GPS Status TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 120 Retrieve Log Display performance monitoring data Retrieve Performance Monitoring Display security parameters for a single user or Retrieve User Security for all users Set the name of the equipment Set Source Identifier TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 121: Commands

    Commands The commands used with the TimeSource 3100 are listed on the following pages. After the command name, a definition of the command is given. The definition is followed by the actual command, followed by the variables that can be used with the command.

  • Page 122: Activate User

    (either uppercase or lowercase can be used). The command format is: ACT-USER:[<tid>]:<uid>:<ctag>::<pid>; Parameter Description <uid> Assigned user name <pid> Assigned password Command Example: ACT-USER::TELECOM:<ctag>::TS3000!!; Response Format: <sid> <date> <time> M <ctag> COMPLD /*LINK:<link>,CMD:<command>*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 123: Cancel User

    To cancel another user, type the command with the UID as the user name to be logged out. The command format is: CANC-USER:[<tid>]:<uid>:<ctag>; Parameter Description <uid> Assigned user name Command Example: CANC-USER::TELECOM:<ctag>; Response Format: <sid> <date> <time> M <ctag> COMPLD /*LINK:<link>,CMD:<command>*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 124: Copy Memory

    The database is automatically copied to nonvolatile memory once per hour. However, if power to the TimeSource 3100 is interrupted before the automatic copying occurs, changes made since the last automatic copy will be lost. To avoid the possibility of losing database changes, the Copy Memory command may be used to copy database changes to nonvolatile memory after any changes are made.
  • Page 125 Copy Memory (cont’d) Command Example: CPY-MEM::TS3100:<ctag>::AUX,,WKG:PGM; Response Format: <sid> <date> <time> M <ctag> COMPLD /*LINK:<link>,CMD:<command>*/ To copy a database from volatile to nonvolatile memory within the TimeSource 3100, the command format is: CPY-MEM:[<tid>]:<aid>:<ctag>::WKG,,AUX:DATA; Item Addressed TS3100 System Database Command Example: CPY-MEM::TS3100:<ctag>::WKG,,AUX:DATA;...

  • Page 126: Delete Equipment

    E1 span A input E1 span B input OPT-y y = 1 to 2 ESCIU port option (990-72020-04 systems only) Command Example: DLT-EQPT::RO-A:<ctag>; Response Format: <sid> <date> <time> M <ctag> COMPLD /*LINK:<link>,CMD:<command>*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 127: Delete User Security

    This command allows a system administrator to delete a user. The command format is: DLT-USER-SECU:[<tid>]:<uid>:<ctag>; Item Addressed <uid> Assigned user name Command Example: DLT-USER-SECU::TELECOM:<ctag>; Response Format: <sid> <date> <time> M <ctag> COMPLD /*LINK:<link>,CMD:<command>*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 128: Edit Communication

    TL1 autonomous messages are sent through port 5550, which connects to an element manager to send one or a group of autonomous messages, then disconnects. Port 5550 is not to be reconfigured. TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 129 Serial port CTS/RTS flow control is not enabled SWCONTROL = b b = ALW XON/XOFF flow control is enabled (See Note 2) b = INH XON/XOFF flow control is not enabled TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 130 Flow control is not implemented on communication port 3 (Craft port). XON/XOFF flow control is simulated for Ethernet ports. Command Example: ED-COM::COM-1:<ctag>:::BAUD=9600,MONMSG=ALW,KEEPALIVE=30, ENDOFTEXT=0,ECHO=ALW,COMPRI=ALW1,AUTOLOGOFF=30,HWCONTROL=ALW, SWCONTROL=ALW, PARITY=NONE,STOP=1; Response Format: <sid> <date> <time> M <ctag> COMPLD /*LINK:<link>,CMD:<command>*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 131: Edit Date

    UTC, from 18:50:30. This is done to accommodate 30-minute time zones and still keep the local time accurate to UTC. If a command includes MODE=UTC, and the GPS signal is not present, the command is denied. TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 132 - The date/time continues to increment normally. Example to set date without changing time or mode: ED-DAT:::<ctag>::2000-08-13; Example to change to local time: ED-DAT:::<ctag>::2000-08-13,07-00-00:MODE=LOCAL; Example to change from local to UTC time: TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 133 ED-DAT:::<ctag>::2000-08-13:MODE=UTC; Response Format: <sid> <date> <time> M <ctag> COMPLD /*LINK:<link>,CMD:<command>*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 134: Edit Equipment

    E1 A output E1 B output OPT-a a=1 to 8 E1 option outputs: 1 through 8 (990-72020-02, 990-72020-06 systems only) a=1 to 2 ESCIU option ports: 1 or 2 (990-72020-04 systems only) TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 135 Alarm conditioning for E1, TOD, and IRIG-B, outputs is disabled IPNE=a.b.c.d a = 0 to 255 IP address of this TimeSource 3100 (See Note 1) (command must be sent from COM1, COM2, b = 0 to 255 or Craft port to set this parameter)
  • Page 136 = 0 No alarm escalation SEVERITY1=x x = CR Severity of initial alarm prior to escalation (See Note 4) x = MJ x = MN x = EV x = NA TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 137 SSMCHANNEL=b b = 4 Uses Sa4 bit b = 5 Uses Sa5 bit b = 6 Uses Sa6 bit b = 7 Uses Sa7 bit b = 8 Uses Sa8 bit TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 138 When the ESCIU detects an LOS on an input PASSTHRU span, the E1 alignment sequence is passed through to the NE with the original input alarm TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 139 Port 5550 makes a connection to this element manager to send TL1 autonomous messages, and closes the connection when the transmission is complete. Port 5551 accepts a connection from this element manager for TL1 commands and responses. TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 140 All commands on DCDUSERPORT having TID which equal SID of the DCD are forwarded to the DCD. Similarly, the responses from the DCD are sent to the provisioned DCDUSERPORT. Response Format: <sid> <date> <time> M <ctag> COMPLD /*LINK:<link>,CMD:<command>*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 141: Enter Equipment

    = A E1 span A input monitor a = B E1 span B input monitor OPT-y y = 1 ESCIU port 1 (990-72020-04 y = 2 ESCIU port 2 systems only) TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 142 Example to set an input to be monitored, but not ensembled: ENT-EQPT:[<tid>]:RO-A:<ctag>; Example to set an input to be monitored and ensembled: ENT-EQPT:[<tid>]:RO-A:<ctag>:::ENSEMBLER=ALW; Response Format: <sid> <date> <time> M <ctag> COMPLD /*LINK:<link>,CMD:<command>*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 143: Enter User Security

    Access level (1 to 5). Levels 1 to 4 do not allow the user to enter or delete users. Level 5 allows the user to enter or delete users. Command Example: ENT-USER-SECU::TELECOM:<ctag>::TS3000!!,,1; Response Format: <sid> <date> <time> M <ctag> COMPLD /*LINK:<link>,CMD:<command>*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 144: Initialize Log

    Initialize Log This command clears the alarm log. The command format is: INIT-LOG:[<tid>]::<ctag>::almlog; Response Format: <sid> <date> <time> M <ctag> COMPLD /*LINK:<link>,CMD:<command>*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 145: Initialize Register

    = A E1 span A input a = B E1 span B input <montype> E1 span A and span B inputs Response Format: <sid> <date> <time> M <ctag> COMPLD /*LINK:<link>,CMD:<command>*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 146: Initialize System

    20 minutes if ALMOUT is SQUELCH, or unstable outputs if ALMOUT is not SQUELCH. The command format is: INIT-SYS:[<tid>]:<aid>:<ctag>::1; Item Addressed TS3100 System software GPS receiver software Response Format: <sid> <date> <time> M <ctag> COMPLD /*LINK:<link>,CMD:<command>*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 147: Operate Alarm Cutoff All

    Operate Alarm Cutoff All This command deactivates (silences) the audible office alarm. The command format is: OPR-ACO-ALL:[<tid>]:ALL:<ctag>; Response Format: <sid> <date> <time> M <ctag> COMPLD /*LINK:<link>,CMD:<command>*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 148: Retrieve Alarm All

    If there is at least one alarm: <sid> <date> <time> M <ctag> COMPLD "<aid>:<ntfcncde>,<condtype>,<srveff>, <ocrdat>,<ocrtm>,,:\"<conddescr>\""... /*LINK:<link>,CMD:<command>*/ Note: Refer to the Troubleshooting chapter for a list of all <conddescr> messages, and the recommended action. TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 149: Retrieve Alarm Equipment

    = A E1 span A input x = B E1 span B input RO-x x = A Remote oscillator A input x = B Remote oscillator B input – GPS receiver TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 150 If there is at least one alarm: <sid> <date> <time> M <ctag> COMPLD "<aid>:<ntfcncde>,<condtype>,<srveff>, <ocrdat>,<ocrtm>,,:\"<conddescr>\"".. / *LINK:<link>,CMD:<command>*/ Note: Refer to the Troubleshooting chapter for a list of all <conddescr> messages, and the recommended action. TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 151: Retrieve Communication

    = 5004 Ethernet user interface port 5004 a = 5551 Ethernet element manager interface port 5551 – All communications ports Response Format: <sid> <date> <time> M <ctag> COMPLD "<aid>:::<spec_block>"... /*LINK:<link>,CMD:<command>*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 152 TL1 commands and responses, sends autonomous messages whether or not logged on a = INH Closes connection, logs off a user (if logged on), and keeps port from use (a port cannot close itself) TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 153 Even parity bit is enabled a = ODD Odd parity bit is enabled a = NONE Parity bit is disabled STOP=a a = 1 1 stop bit a = 2 2 stop bits TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 154: Retrieve Condition All

    If there is at least one alarm or event: <sid> <date> <time> M <ctag> COMPLD "<aid>:<ntfcncde>,<condtype>,<srveff>, <ocrdat>,<ocrtm>,,,:\"<conddescr>\"".. /*LINK:<link>,CMD:<command>*/ Note: Refer to the Troubleshooting chapter for a list of all <conddescr> messages, and the recommended action. TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 155: Retrieve Condition Equipment

    System SPAN-x x = A E1 span A input E1 span B input RO-x x = A Remote oscillator A input Remote oscillator B input – GPS receiver Command Example: RTRV-COND-EQPT::TS3100:<ctag>; TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 156 If there is at least one alarm: <sid> <date> <time> M <ctag> COMPLD "<aid>:<ntfcncde>,<condtype>,<srveff>, <ocrdat>,<ocrtm>,,,\"<conddescr>\""... /*LINK:<link>,CMD:<command>*/ Note: Refer to the Troubleshooting chapter for a list of all <conddescr> messages, and the recommended action. TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 157: Retrieve Equipment

    E1 B output OPT-a x=1 to 8 Additional E1 outputs (990-72020-02 systems only) Mixed E1/T1 outputs (990-72020-06 systems only) x=1 to 2 ESCIU ports: 1 or 2 (990-72020-04 systems only) Command Example: RTRV-EQPT::TS3100:<ctag>; TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 158 = ALW or During holdover, the traffic-bearing E1 spans on the ESCIU module pass through the (990-72020-04 TimeSource 3100 without being re-timed (ALW) Systems only) or the E1 spans continue to be re-timed (INH) FREQ=a Frequency for both remote oscillator inputs is 5...
  • Page 159 0 deactivates the timer; for example, 100 = 10s) IPNTP=a a=ALW NTP feature activated DCDPASSTHRU DCD port communication is inhibited ALW1 COM1 is the DCD interface port ALW2 COM2 is the DCD interface port TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 160 SIGNAL=b b=ANALOG Span input signal is 2.048 MHz b=DIGITAL Span input signal is 2.048 Mb/s SSMCHANNEL=b Uses Sa4 bit Uses Sa5 bit Uses Sa6 bit Uses Sa7 bit Uses Sa8 bit TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 161 When the ESCIU detects an LOS on one of its PASSTHRU input spans, the E1 alignment sequence is passed through to the NE with the original input alarm TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 162 = LOS LOS alarm A & B x = AIS AIS alarm x = ERROR ERROR alarm RO A & B ALARM=x x = LOS LOS alarm x = ERROR ERROR alarm TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 163 NSA flag. Once this condition has existed for 72 hours, TS3100 will generate a major alarm with an SA flag. These parameters can then be verified using the RTRV-EQPT command. TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 164: Retrieve Gps Status

    This command displays the position of the GPS receiver, UTC time, and status information for each of the GPS satellites in view. The command format is: RTRV-GPS-STAT:[<tid>]:GPS:<ctag>; Response Format: <sid> <date> <time> M <ctag> COMPLD "GPS:LAT=x,LONG=x,<alt>,<utc>” "GPS:SAT-x,USE=X,CNO=x,ELEV=x,AZ=x,LOCK=x” /*LINK:<link>,CMD:<command>*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 165 ELEV=a a = dd Satellite elevation in degrees AZ=a a = ddd Satellite azimuth in degrees LOCK=a a = 1 to 2500 Seconds since the receiver locked to the satellite carrier TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 166: Retrieve Header

    Retrieve Header This command allows for NMA integration to use as a keep alive message. The command format is: RTRV-HDR:[<tid>]::<ctag>; Response Format: RTRV-HDR:::114; TELECOM1 1997-12-08 15:04:13 M 114 COMPLD TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 167: Retrieve Inventory

    SOFTVER_TS3100=a, SOFTVER_GPS=a, SOFTVER_DEV=a" /*LINK: x, CMD:<command>*/ Response Format example (additional E1 outputs): TS3100 1970-01-01 01:03:05<time> M C COMPLD "TS3100::::CARD=TS3100, MACID=00:B0:AE:00:13:83, TYPE=E1,E1 option board PART=090-72020-02, SERIAL=E25144, SOFTVER_TS3100=1.05.02, SOFTVER_GPS=1.02.04, SOFTVER_DEV=1.03.02-1.01.01" /*LINK: 1, CMD:RTRV-INVENTORY::TS3100:C*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 168: Retrieve Inventory (Cont'd)

    SERIAL=a – a = Serial number SOFTVER_TS3100=a a = bb.cc.dd System software version SOFTVER_GPS=a a = bb.cc.dd GPS receiver software version SOFTVER DEV=a a = bb.cc.dd or Device software version bb.cc.dd-ee.ff.gg TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 169: Retrieve Log

    HOD=0 to 23, MOH=0 to 59, SOM=0 to 59 <conddescr> Text string of no more than 64 characters enclosed within a pair of escape quotes (\) <dgntype> TL1 identifier up to 16 characters in length TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 170: Retrieve Performance Monitoring

    Retrieve Performance Monitoring This command retrieves the performance monitoring data from the TimeSource 3100. This data includes MTIE, TDEV, PHASE 1S, and PHASE 1 M. For current 24 hour data, MTIE, TDEV, and PHASE 1 S data are grouped every 15 minutes. In addition, there are 7 daily summaries of MTIE, TDEV, and PHASE1M.
  • Page 171 One day summary from the last 7 days of daily summaries. To select one daily summary, enter mondat, but do not enter montm. Any mondat not in the previous 7 day window is denied. TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 172 = 1 to 31 Monitor date, day of the month MONTM=a-b a = 0 to 23 Monitor time, hour of the day b = 0 to 59 Monitor time, minute of the hour TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 173 M G COMPLD "SPAN-A:MTIE-1S,1,COMPL ,,,,2000-05-25,11-00-00" "SPAN-A:MTIE-4S,1,COMPL ,,,,2000-05-25,11-00-00" "SPAN-A:MTIE-10S,1,COMPL ,,,,2000-05-25,11-00-00" "SPAN-A:MTIE-40S,1,COMPL ,,,,2000-05-25,11-00-00" "SPAN-A:MTIE-100S,1,COMPL ,,,,2000-05-25,11-00-00" "SPAN-A:MTIE-300S,1,COMPL ,,,,2000-05-25,11-00-00" "SPAN-A:MTIE-900S,1,COMPL ,,,,2000-05-25,11-00-00" ,,,,2000-05-25,11-00-00" "SPAN-A:MTIE-1800S,1,COMPL ,,,,2000-05-25,11-00-00" "SPAN-A:MTIE-3600S,1,COMPL ,,,,2000-05-25,11-00-00" "SPAN-A:MTIE-7200S,1,COMPL ,,,,,2000-05-25,11-00-00" "SPAN-A:MTIE-14400S,1,COMPL ,,,,2000-05-25,11-00-00" "SPAN-A:MTIE-28800S,1,COMPL ,,,,2000-05-25,11-00-00" "SPAN-A:MTIE-86400S,1,COMPL ,,,,2000-05-25,11-00-00" /*LINK:5002,CMD:RTRV-PM-EQPT:: SPAN-A:G::MTIE*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 174 One day summary from the last 7 days of daily summaries. To select one daily summary, enter mondat, but do not enter montm. Any mondat not in the previous 7 day window is denied. TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 175 = 1 to 31 Monitor date, day of the month MONTM=a-b a = 0 to 23 Monitor time, hour of the day b = 0 to 59 Monitor time, minute of the hour TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 176 TDEV Response Example: TS3100-2009 2000-05-25 11:01:58 M G COMPLD "SPAN-A:TDEV-1S,0,COMPL ,,,,,2000-05-25,11-00-00" "SPAN-A:TDEV-2S,0,COMPL ,,,,,2000-05-25,11-00-00" "SPAN-A:TDEV-4S,0,COMPL ,,,,,2000-05-25,11-00-00" "SPAN-A:TDEV-8S,0,COMPL ,,,,,2000-05-25,11-00-00" "SPAN-A:TDEV-16S,0,COMPL ,,,,,2000-05-25,11-00-00" "SPAN-A:TDEV-32S,0,COMPL ,,,,,2000-05-25,11-00-00" "SPAN-A:TDEV-64S,0,COMPL ,,,,,2000-05-25,11-00-00" "SPAN-A:TDEV-128S,0,COMPL ,,,,,2000-05-25,11-00-00" "SPAN-A:TDEV-256S,0,COMPL ,,,,,2000-05-25,11-00-00" "SPAN-A:TDEV-512S,0,COMPL ,,,,,2000-05-25,11-00-00" "SPAN-A:TDEV-1024S,0,COMPL ,,,,,2000-05-25,11-00-00" /*LINK:5002,CMD:RTRV-PM-EQPT:: SPAN-A:G::TDEV*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 177 Retrieve Performance Monitoring (cont’d) PHASE1S Response Format: <sid> <date> <time> M <ctag>COMPLD "SPAN-a:PHASE1S,<monval>,<∆>,<∆>,<∆>,<∆>, <∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>, <∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>, <∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>, <∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>, <∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>, <∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>, <∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>, <∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>, <∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<vldty> ,,,,<mondat>,<montm>" "SPAN-a:PHASE1S,<monval>,<∆>,<∆>,<∆>,<∆>, <∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>, <∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>, <∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>, <∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>, <∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>, <∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>, <∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>, <∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<∆>, <∆>,<∆>,<∆>,<∆>,<∆>,<∆>,<vldty> ,,,,<mondat>,<montm>" TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 178 The 900 seconds of data is broken into 9 groups of 100 seconds. For each group of 100 seconds, the first value is the absolute 1 second phase for that group. The absolute 1 second phase value is followed by 99 seconds of delta phase values. TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 179 = 1 to 31 Monitor time, day of the month MONTM=a-b a = 0 to 23 Monitor time, hour of the day b = 0 to 59 Monitor time, minute of the hour TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 180 ,0,0,0,0,0,0,0,0,0,0,0,0,COMPL,,,,2000-10-13,12-46-40" "SPAN-A:PHASE1S,-321,0,0,0,0,0,0,0,0,0,0,0,0,0, 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 ,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0, 0,1,0,0,0,0,0,0,0,0,0,0,0,0,0,0,-1,0,0,0,0,0,0,0, 0,0,0,0,0,0,0,0,0,0,0,0,0,COMPL,,,,2000-10-13,12-48-20" "SPAN-A:PHASE1S,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0, 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 ,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0, 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 ,0,0,0,0,0,0,0,0,0,0,0,NA,,,,2000-10-13,12-50-00" "SPAN-A:PHASE1S,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0, 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 ,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0, 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 ,0,0,0,0,0,0,0,0,0,0,0,NA,,,,2000-10-13,12-51-40" "SPAN-A:PHASE1S,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0, 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 ,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0, 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 ,0,0,0,0,0,0,0,0,0,0,0,NA,,,,2000-10-13,12-53-20" "SPAN-A:PHASE1S,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0, 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 ,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0, 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 ,0,0,0,0,0,0,0,0,0,0,0,NA,,,,2000-10-13,12-55-00" "SPAN-A:PHASE1S,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0, 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 ,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0, 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 ,0,0,0,0,0,0,0,0,0,0,0,NA,,,,2000-10-13,12-56-40" TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...
  • Page 181 Note: PHASE1M Data types: • The TimeSource 3100 collects a full 7 days of 1 minute phase data. • The 1 minute phase data is displayed in 1 hour groups. Each request for 1 minute phase is synchronized to the hour.
  • Page 182 Monitor time, hour of the day b = 0 to 59 Monitor time, minute of the hour PHASE1M Response Example: TS3100-2009 2000-05-25 11:01:58 M G COMPLD "SPAN-A:PHASE1M,0,0,0,0,0,0,0,0,0,0,0,0, 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 ,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0, 0,0,COMPL,,,,,2000-05-25,100-00" /*LINK:5002,CMD:RTRV-PM-EQPT:: SPAN-A:G::PHASE1M*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 183: Retrieve User Security

    Description <uap> Access level (1 to 5) <uout> (Displayed, but not implemented) Password for this account expires in this number (0 to 180) of days of inactivity; 0 indicates no expiration TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 184: Set Source Identifier

    This command sets the name of the equipment sending the message. The command format SET-SID:[<tid>]::<ctag>::<sid>; Parameter Description <sid> Source identifier – can be up to 20 uppercase or lowercase ASCII characters Response Format: <sid> <date> <time> M <ctag> COMPLD /*LINK:<link>,CMD:<command>*/ TimeSource 3100 TL1 Reference 097-72020-01 Issue 9: November 2003...

  • Page 185: Chapter 5 Troubleshooting

    Troubleshooting This chapter provides troubleshooting information using front-panel lamps and error messages. It also describes how to replace a card, return equipment, get technical and/or sales assistance, and obtain manual updates. Chapter 5...

  • Page 186: Troubleshooting With Front Panel Items

    Status Alarms (Pushbutton) (Lamp) 990-72020-01, -02, -05, -06 Systems Retimed Span B Span Remote Retimed A & B OSC A,B Span A Status Alarms Alarms CRIT Status Alarms (Pushbutton) (Lamp) 990-72020-04 Systems TimeSource 3100 Troubleshooting 097-72020-01 Issue 9: November 2003...
  • Page 187 Check the remote oscillator input signal), which has existed on this signal, source, cable, and user alarm setting, has escalated to connections. Verify the input a minor alarm. frequency matches the equipment configuration. TimeSource 3100 Troubleshooting 097-72020-01 Issue 9: November 2003...
  • Page 188 There is no major alarm. None required The system has been in holdover on Refer to Table M to determine which this user alarm setting. type and combination of alarms exist, and the recommended action. TimeSource 3100 Troubleshooting 097-72020-01 Issue 9: November 2003...
  • Page 189 3100 System. only) Traffic-carrying E1 data stream is Refer to Table M to troubleshoot the bypassing the TimeSource 3100 GPS, SPAN x, and ROx error System and not being retimed messages. because the system is in holdover. TimeSource 3100...

  • Page 190: Troubleshooting With Error Messages

    Note: If only the character “C” is displayed on the terminal every few seconds, the TimeSource 3100 system has restarted with corrupt software. Download and install the system software again, using the procedure in the Software Release Document that came with the software.
  • Page 191 TNC antenna connector. 3. If the voltage is not 18 Vdc ±2 Vdc, replace the TimeSource 3100 card using Procedure F. 4. If the voltage is 18 Vdc ±2 Vdc, measure the current between the antenna...
  • Page 192 If accompanied by the GPS ERROR LOW CURRENT alarm: FAULT 1. Check the cable connections between the TimeSource 3100 Shelf and the antenna. 2. If the error repeats, remove the antenna cable from the connector panel of the shelf and measure the dc voltage from...
  • Page 193 If this occurs during steady-state operation: 1. Check that the ambient air temperature is within the TimeSource 3100 environmental specifications. If not, correct the ambient temperature with heating or air conditioning. 2. If the ambient air temperature is within the TimeSource 3100 environmental specifications, replace the plug-in card.
  • Page 194 ESCIU port has been lost. input signal source, ESCIU port cable, and ESCIU port connections. ESCIU x SLIP The specified ESCIU port has a Troubleshoot the traffic-carrying span frame slip. input signal source. TimeSource 3100 Troubleshooting 097-72020-01 Issue 9: November 2003...
  • Page 195 2. If the ambient air temperature is within the TimeSource 3100 environmental specifications, replace the plug-in card. Note: This event will escalate to a minor alarm per the user alarm setting.

  • Page 196: Card Replacement

    Tighten the knurled screw above each latching lever to secure the card in the shelf. Unplug, and remove, the grounding wrist strap. Reconfigure the system per application requirements. End of Procedure TimeSource 3100 Troubleshooting 097-72020-01 Issue 9: November 2003...
  • Page 197 Figure 31. Front of Shelf Jack Retaining Latching Latching Retaining Screw Lever Lever Screw 990-72020-01, -02, -05 -06 Systems Jack Retaining Latching Latching Retaining Screw Lever Lever Screw 990-72020-04 Systems TimeSource 3100 Troubleshooting 097-72020-01 Issue 9: November 2003...

  • Page 198: Repair And Return

    Repair and Return When returning defective equipment for factory repair, obtain the following information prior to calling Symmetricom: • A complete description of the trouble (alarms, equipment behavior, etc.), part number, serial number, issue/revision level, and warranty expiration date. •...
  • Page 199 Street B Lot 52 Aguadilla, Puerto Rico 00603 Repaired equipment is typically shipped within 30 days of receipt by Symmetricom, or per contract terms. Shipping costs to Symmetricom are paid by the customer; shipping costs back to the customer are paid by Symmetricom.

  • Page 200: Technical Assistance

    San Jose, CA 95131-1017 U.S.A. Call Center: 1-888-367-7966 (from inside U.S.A. only - toll-free) 1-408-428-7907 Europe, Middle East, and Africa (EMEA) Call Center: +44 (0) 1189 699 799 Fax: 1-408-428-7998 E-mail: info@symmetricom.com Internet: http://www.symmetricom.com TimeSource 3100 Troubleshooting 097-72020-01 Issue 9: November 2003...

  • Page 201: Manual Updates

    When going to the preceding Web address, it is necessary to register if you are a new user. If you are a currently registered user, enter your user name and password, and log in. TimeSource 3100 Troubleshooting 097-72020-01 Issue 9: November 2003...
  • Page 202 TimeSource 3100 Troubleshooting 097-72020-01 Issue 9: November 2003...

  • Page 203: Chapter 6 Specifications

    Chapter 6 Specifications This chapter provides equipment specifications.

  • Page 204: Antenna

    Dimensions: (excluding mount) Height: 31.4 cm Diameter: 7.6 cm Weight: 255 g Operating Temperature: –30° C to +80° C Storage Temperature: –40° C to +80° C Operating Humidity: 0% to 100% relative humidity TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 205: Communication Ports

    1200 b/s 2400 b/s 4800 b/s 9600 b/s (factory default) 19.2 kb/s 38.4 kb/s 57.6 kb/s 115 kb/s Data Bits: Parity Bit: None Even Stop Bits: Flow Control: None Software (XON/XOFF) Hardware (CTS/RTS) TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...
  • Page 206 1200 b/s 2400 b/s 4800 b/s 9600 b/s (factory default) 19.2 kb/s 38.4 kb/s 57.6 kb/s 115 kb/s Data Bits: Parity Bit: None Even Stop Bits: Flow Control: None Software (XON/XOFF) Hardware (CTS/RTS) TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...
  • Page 207 Pin that receives data: Baud Rate: 1200 b/s 2400 b/s 4800 b/s 9600 b/s (factory default) 19.2 kb/s 38.4 kb/s 57.6 kb/s 115 kb/s Data Bits: Parity Bit: None Even Stop Bits: Flow Control: NONE TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 208: Ethernet Port

    Ethernet Port Connector Type: RJ-45 (10Base-T) Connector Label: E-NET Connector Location: Connector panel Electrical Interface: 10Base-T Ethernet Data Rate: 10Mb/s Protocol: TCP/IP (interface) Setup Language: TL1 (application layer) TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 209: Time Of Day Outputs

    Connector Label: Connector Location: Connector panel Electrical Interface: RS-485 Baud Rate: 9600 b/s Data Bits: Parity Bit: None Stop Bit: Data Format: See Figure 32 Figure 32. NTP Type 4 Data Format TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 210: Time Of Day Outputs (Cont'd)

    Connector Location: Connector panel Electrical Interface: RS-485 Baud Rate: 9600 b/s Bit Configuration: 8 data bits, No parity, 1 stop bit Data Format: See Figure 33 Figure 33. NTP Type 4 Data Format TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 211: Time Of Day Outputs (Cont'd)

    Binary Coded Decimal (BCD) Seconds: 0 – 59 Minutes: 0 – 59 Hours: 0 – 23 Days: 0 – 364 Years: 0 – 99 Non BCD Seconds of Day: 0 – 86399 TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 212: Remote Oscillator Inputs

    Connector Label: REM OSC A REM OSC B Connector Location: Connector panel 75 Ω Impedance: Frequency: 5 MHz 10 MHz Format: Sine wave Amplitude: 1 V rms minimum 3.5 V rms maximum TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 213: E1 Inputs

    120 Ω ±5% balanced or Impedance: 75 Ω ±5% unbalanced Bit Rate: 2.048 Mb/s Format: Line Code: HDB3 State: Enable Disable Framing: CAS4 CCS4 Channels: Amplitude: +3 dB to –33 dB Framing: CAS4 CCS4 TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 214: Analog 2.048 Mhz Inputs

    Connector Label: BNC: SPAN IN A SPAN IN B Wire-Wrap (2 sets) Connector Location: Connector panel 120 Ω ±5% balanced or Impedance: 75 Ω ±5% unbalanced Bit Rate: 2.048 MHz Format: Analog TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 215: Pps Output

    1.8 µs per day with ST2E remote oscillator input (0 °C to +50 °C, ±5 °C) Pulse width: 1 µs pulse Rise time: Less than 20 ns Amplitude: Transistor-transistor logic (TTL) levels TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 216: E1 Outputs

    ST2E remote oscillator input Format: Framed all 1s Line Code: HDB3 3.0 V nominal terminated with 120 Ω balanced Amplitude: 2.37 V nominal terminated with 75 Ω unbalanced Framing: CAS4 CCS4 Output During Alarms: Squelch TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 217: Additional E1 Outputs (990-72020-02 System Only)

    ST2E remote oscillator input Format: Framed all 1s Line Code: HDB3 3.0 V nominal terminated with 120 Ω balanced Amplitude: 2.37 V nominal terminated with 75 Ω unbalanced Framing: CAS4 CCS4 Output During Alarms: Squelch TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 218: Analog 2.048 Mhz Outputs

    30 days (0 °C to +50 °C, ±5 °C) with an ST2E remote oscillator input Format: Square wave 1.5 V nominal terminated with 120 Ω balanced Amplitude: 1.18 V nominal terminated with 75 Ω unbalanced TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 219: Additional Analog Outputs (990-72020-02 System Only)

    30 days (0 °C to +50 °C, ±5 °C) with an ST2E remote oscillator input Format: Square wave 1.5 V nominal terminated with 120 Ω balanced Amplitude: 1.18 V nominal terminated with 75 Ω unbalanced TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 220: Mixed E1/T1 Outputs (990-72020-06 System Only)

    ANSI T1.101 network specification 99% probability 1 x 10 for 30 days (0 °C to 50 °C ± 5°C) with an ST2E remote oscillator input TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 221: Mixed E1/T1 Outputs (Cont'd)

    ANSI T1.101 network specification 99% probability (rubidium) 1 x 10 for 30 days over a 10 °C range between 0 °C and 50 °C) with an ST2E remote oscillator input (quartz) TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 222: 10 Mhz Output

    –140 dBc @ 1 kHz –145 dBc @ 10 kHz Harmonic Distortion: –40 dBc Spurious Distortion: –70 dBc Format: Sine wave 1 V peak-to-peak minimum, 50 Ω termination Amplitude: 3.7 V peak-to-peak typical, 50 Ω termination TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 223: Esciu Ports (990-72020-04 System Only)

    Maximum cable length: 150 m (either direction, to or from DDF) CSU Functionality: None Output During LOS Alarm: Input jitter tolerance: ITU G.823 (1993) requirements ± 125 µs Input wander tolerance: TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 224: Office Alarms

    Span (A, B) Remote Oscillator (A, B) 990-72020-04 System only: Retimed spans: A, B, BYP Type: Light emitting diode Front Panel Control Label: Type: Push button switch Function: Alarm cutoff (deactivates audible office alarms) TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 225: Simple Network Time Protocol

    IP address at Stratum 2 to signify that the reference is the TimeSource clock itself. 3. SNTP packet will indicate “clock not synchronized” in LI field as a “3” value after user defined alarm integration time. Password Activated: Contact factory TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...

  • Page 226: Power

    12.7 cm offset (48.5 cm rack only) Width: 48.3 cm Height: 22.2 cm maximum Depth: 30.5 cm maximum Weight: 5.9 kg Shelf Environmental Operating Temperature: 0 °C to +50 °C Operating Humidity: Up to 95% noncondensing Electromagnetic TimeSource 3100 Specifications 097-72020-01 Issue 9: November 2003...
  • Page 227 2.048 MHz input specifications 2.048 MHz output specifications 5 MHz Isolator kit 8 additional E1/T1 outputs 8 mixed E1/T1 outputs 990-72020-01 TimeSource 3100 system 21, 42 990-72020-02 TimeSource 3100 system 22, 44 990-72020-04 TimeSource 3100 system 990-72020-05 TimeSource 3100 System...
  • Page 228 Application, TimeWizard Application, TimeWizard Software Installation atag parameter, automatic message tag automatic message tag autonomous messages battery failure, troubleshooting BesTime algorithm BesTime Ensemble Timing Generator Bridging mode BT3 Warmup event TimeSource 3100 Index 097-72020-01 Issue 9: November 2003...
  • Page 229 COM2 cable pinout current settings specifications command format, TL1 communications, changing parameters conddescr parameter, condition description condeff parameter, equipment condition condition description condtype parameter, alarm condition Connector panel TimeSource 3100 Index 097-72020-01 Issue 9: November 2003...
  • Page 230 E1 input cabling E1 output cabling E1 outputs E1/T1 output specifications earth ground connecting installing TimeSource 3100 Index 097-72020-01 Issue 9: November 2003...
  • Page 231 TL1 commands format, TL1 response frame ground front panel lights, troubleshooting with fuse requirements gateway address 16, 19 antenna description error troubleshooting overview retrieving status TimeSource 3100 Index 097-72020-01 Issue 9: November 2003...
  • Page 232 51–55 antenna ground isolation module lightning suppressor overview output module IP address IPGATE IPSUBNET IRIG-B TOD outputs IRIG-B TOD specifications isolation module, installing Isolator kit, 5 MHz Lamp, CRIT LEDs, troubleshooting with TimeSource 3100 Index 097-72020-01 Issue 9: November 2003...
  • Page 233 NTP password NTP specifications NTP TimeServer overview occurrence date occurrence time ocrdat parameter, occurrence date ocrtm parameter, occurrence time offset rack mouting operate alarm cutoff all command OPTIONS I/O connector output module installing TimeSource 3100 Index 097-72020-01 Issue 9: November 2003...
  • Page 234 ESCIU ESCIU connector Ethernet post-mounting the antenna power specifications power supply overview Power Up Restart event 83–90 powering up the unit private identifier TimeSource 3100 Index 097-72020-01 Issue 9: November 2003...
  • Page 235 GPS status command Retrieve Header retrieve inventory command retrieve log command retrieve performance monitoring command retrieve user security command returning the unit to Symmetricom reverse polarity protection ring ground sales support serial number, displaying set source identifier command Settling Period event...
  • Page 236 T1 output specifications target identifier TDEV displaying data resetting technical support termperature error tid parameter, target identifier Time of Day output TimeWizard application TimeWizard Software Installation application timing source characteristics command format conventions TimeSource 3100 Index 097-72020-01 Issue 9: November 2003...
  • Page 237 XON/XOFF TimeSource 3100 Index 097-72020-01 Issue 9: November 2003...
  • Page 238 TimeSource 3100 Index 097-72020-01 Issue 9: November 2003...

Table of Contents
