Symmetricom TimeSource 3600 User Manual page 143

Aid Parameter
OPT-a ALMOUT=b
(ESCIU
ports on
990-72060-
04 systems
only)
OPT-a ALMOUT=b
(990-72060
-06
systems
only)
FRAMING =b
TS3600 DCDPASSTHRU
DCDUSERPORT=x
(See Note: 13)
097-72060-01 Revision J – June, 2007
Value
b = AIS When the ESCIU detects LOS on an input
span, an all-ones signal (AIS), without the E1
frame alignment sequence, is output to the
downstream network element
b = All traffic passes through to the downstream
PASSTHRU network element, including the LOS alarm
signal
b = AIS Output is AIS during alarm
b = Output is squelched during alarm
SQUELCH
b = SSM Outputs are at 'STU' quality level for ESF
framing and at 'SSUT' quality level for CAS4
and CCS4 framing during holdover alarm (SSM
requires CAS4, CCS4,or ESF output framing)
b = CAS Output framing is CAS
b = CAS4 Output framing is CAS4
b = CCS Output framing is CCS
b = CCS4 Output framing is CCS4
b = D4 Output framing is D4
b = ESF Output framing is ESF
b = NONE Output framing is NONE (analog)
(see Note: 12)
INH DCD port communication is inhibited
ALW1 COM1 is the DCD interface port
ALW2 COM2 is the DCD interface port
x = 1 COM1
x = 2 COM2
x = 3 or 5001, COM3 or IP port 5001 to 5004
5002, 5003,
5004
Chapter 4 TL1 Reference
Commands
Description
TimeSource 3600 User's Guide 143
