1.2.2

Optional Accessories

Table 3 Cooling/IO Shield
Article
conga-IA50/CSP
conga-IA50/i-CSP
conga-IC87/97- CSA Retention Frame
Table 4 Memory Modules
Article
DDR3L-SODIMM-1600 (2 GB)
DDR3L-SODIMM-1600 (4 GB)
DDR3L-SODIMM-1600 (8 GB)
Table 5 Cables
Article
cab-ThinMini-ITX-SATA-Power
cab-ThinMini-ITX-UART
cab-ThinMini-ITX-USB2.0-Single
cab-ThinMini-ITX-USB20-Twin
cab-ThinMini-ITX-USB30-Twin
cab-ThinMini-ITX-LVDS-Open End
cab-ThinMini-ITX-BKLT
cab-DP to HDMI
cab-ThinMini-ITX-SATA-Power (50cm lenght)
cab-ThinMini-ITX-SATA-Power (30cm length)
cab-ThinMini-ITX-USB30-Micro B
SATA III cable 30 cm, straight/straight
SATA III cable 30 cm, down/straight
Table 6 Adapters
Article
conga-Thin MITX/eDP to DP Adapter
conga-Thin MITX/eDP to HDMI Adapter
Copyright © 2017 congatec AG
Part No. Description
052830 Passive cooling solution with Thin Mini-ITX height for open die variants (Celeron
052831 Passive cooling solution with Thin Mini-ITX height for lidded die variants (Atom™)
052254 Retention frame for conga-IC87/97/170/IA5 standard cooling
Part No. Description
068755 Certified 2 GB DDR3L SODIMM memory module with 1600 MT/s (PC3L-12800S)
068756 Certified 4 GB DDR3L SODIMM memory module with 1600 MT/s (PC3L-12800S)
068757 Certified 8 GB DDR3L SODIMM memory module with 1600 MT/s (PC3L-12800S)
Part No. Description
14000120 Power cable for SATA and micro-SATA devices
14000121 UART cable with 2x5 pin female housing and D-Sub male connector
14000122 20cm USB 2.0 cable with 1x5 pin female housing and one USB 2.0 Type A female connector
14000123 20cm USB 2.0 cable—Twin with 2x5pin female header and two USB 2.0 Type A female connectors
14000124 25cm USB 3.0 cable—Twin with 2x10pin female header and two USB 3.0 Type A female connectors
14000125 ACES 40 pin LVDS cable with open end
14000127 CHYAO SHIUNN 8 pin backlight cable with open end
14000128 20 pin male DP to 19 pin female HDMI
14000135 50cm SATA power cable with 2x15 pin female connectors
14000136 30cm SATA power cable with 2x15 pin female connectors
14000198 30cm USB 3.0 cable with 2x10 pin female housing and one USB 3.0 Micro B female connector
48000029 30cm SATA III cable with straight connectors on both ends
48000030 30cm SATA III cable with down and straight connector
Part No. Description
052231 eDP to standard DisplayPort evaluation adapter for congatec Thin Mini-ITX boards
052232 eDP to standard HDMI evaluation adapter for congatec Thin Mini-ITX boards
IA50m10
and Pentium )
® ®
12/59
