Table 8 Measurement Description
The power consumption values were recorded during the following system states:
System State Description
S0: Minimum value Lowest frequency mode (LFM) with minimum core voltage during
desktop idle.
S0: Maximum value Highest frequency mode (HFM/Turbo Boost).
S0: Peak value Highest current spike during the measurement of "S0: Maximum
value". This state shows the peak value during runtime.
S3 SBC is powered by VCC_5V_SBY.
S5 SBC is powered by VCC_5V_SBY.
Note
The fan and SATA drives were powered externally. All other peripherals, except the LCD monitor, were disconnected before measurement.
Table 9 Power Consumption Values
The tables below provide additional information about the power consumption data for each of the conga-IA5 variants offered. The values are
recorded at various operating modes.
Part Memory H.W BIOS
No. Size Rev. Rev.
052801 4 GB A.0 IA50R019
052802 4 GB A.1 IA50R019
052803 4 GB A.1 IA50R019
052820 4 GB A.1 IA50R019
052821 4 GB A.0 IA50R019
052811 4 GB A.0 IA50R019
Note
With fast input voltage rise time, the inrush current may exceed the measured peak current.
Copyright © 2017 congatec AG
OS CPU
(64-bit)
Variant
Windows 10 Intel Atom™ x7 E3950
® ®
Windows 10 Intel Atom™ x5 E3940
® ®
Windows ® 10 Intel ® Atom™ x5 E3930
Windows ® 10 Intel ® Pentium ® N4200
Windows ® 10 Intel ® Celeron ® N3350
Windows 10 Intel Atom™ x7 E3950
® ®
Comment
The CPU was stressed to its maximum frequency.
Consider this value when designing the system's power supply to
ensure that sufficient power is supplied during worst case scenarios.
Current (Amp.)
Cores Base/Burst S0: S0:
Freq. (GHz) Min Max
4 1.6/2.0 0.31 1.92
4 1.6/1.8 0.31 1.48
2 1.3/1.8 0.31 1.14
4 1.1/2.5 0.31 1.32
2 1.1/2.4 0.31 1.20
4 1.6/2.0 0.31 1.92
IA50m10
S0: S3 S5
Peak
2.14 0.27 0.22
1.58 0.26 0.20
1.23 0.27 0.21
2.15 0.27 0.21
1.94 0.27 0.22
2.14 0.27 0.22
