Pin Signal
Pin Signal
53
REFCLK-
54
PEWAKE#
55
REFCLK+
56
N.C
57
GND
58
N.C
59
N.C
60
N.C
61
N.C
62
N.C
63
N.C
64
N.C
65
N.C
66
N.C
67
RESET#
68
SUSCLK
69
CONFIG_1
70
+3.3V
71
GND
72
+3.3V
73
GND
74
+3.3V
75
CONFIG_2
Connector Type
X12: M.2 type B slot (compatible with card size 3042 or 2242)
Note
Optionally, the micro-SIM card slot (connector X10) can be connected to the M.2 socket instead.
Copyright © 2017 congatec AG
IA50m10
38/59
