1.2.2

Optional Accessories

Table 3 Accessories
Article
conga-PA5/HSP-T
conga-PA5/i-HSP-T
conga-PA5/CSP-T
conga-PA5/i-CSP-T
1.2.3

Optional Cables

Table 4 Cables
Article
cab-DP to HDMI Passive
cab-Pico-ITX-LVDS
cab-Pico-ITX-Backlight
SATA III cable 30 cm
conga-PA5 Cable Kit
Table 5 Cable Kit
Article
cab-Pico-ITX-USB20-Twin
cab-Pico-ITX-Audio Cable Adapter
cab-Pico-ITX-Buttons-LED
cab-Pico-ITX-GPIO
cab-Pico-ITX-RS232
cab-Pico-ITX-RS422
cab-Pico-ITX-RS485
cab-Pico-ITX-External-Power
cab-Pico-ITX-Feature
cab-Pico-ITX-Power
cab-Pico-ITX-SATA-Power
SATA III cable 30 cm
miniPCIe metal baffle
Copyright © 2017 congatec AG
Part No. Description
048150 Heatspreader for Pico ITX board conga-PA5 (for boards with standard -non lidded- CPUs)
048151 Heatspreader for Pico ITX board conga-PA5 (for boards with lidded CPUs -with integrated heat spreader)
048152 Passive Cooling for Pico ITX board conga-PA5 (for boards with standard (non lidded) CPUs)
048153 Passive Cooling for Pico ITX board conga-PA5 (for boards with lidded CPUs -with integrated heat spreader)
Part No. Description
14000128 22.5cm Displayport 20 pin male > HDMI-A 19 pin female up to 1920 x 1200 @ 60 Hz (1.1 and High Speed HDMI standard)
TBD TBD
TBD TBD
48000030 30 cm SATA III cable with data transfer rate of up to 6 Gbps suitable for conga-IGX; Connector: down / straight
14000203 For the contents of the cable kit, see table 5 "Cable Kit" below.
Part No. Description
14000123 20cm from internal 2x5pin, 2.54mm Female Header to 2x USB A (Female W/Molding)
14000146 15cm audio Cable Adapter.
14000147 30cm buttons and LED cable.
14000151 15cm GPIO cable with open end.
14000152 15cm RS232 cable adapter, DSUB9 Male.
14000153 15cm RS422 cable adapter, DSUB9 Male.
14000154 15cm RS485 cable adapter, DSUB9 Male.
14000157 100cm external power cable with 4mm banana plugs (optimized to supply Pico-ITX from laboratory power source).
14000161 15cm feature cable with open end.
14000172 15cm internal power cable for industrial versions.
14000205 15cm SATA power cable to supply HDD from Backlight power connector for 2.5" HDD only (+5V only)
48000029 30 cm SATA III cable with data transfer rate of up to 6 Gbps; Connector: straight / straight
56000071 miniPCIe metal baffle (extender) 1x Metal baffle + 4x Screws
