Congatec conga-IA5 User Manual page 56

Pin Signal name Pin Type Voltage
28 GPI3 Input
29 GPI4 Input
30 GPI5 Input
31 GPI6 Input
32 GPI7 Input
33 SLP_S3# Output
34 SLP_S4# Output
35 SLP_S4# Output
36 CGBC_LID_BTN_L Input
37 CGBC_SLP_BTN_L Input
38 PM_THRM# Input
39 WDOUT Output
40 WDTRIG_IN# Input
41 CGBC_SDA I/OD
42 PWR_OK Input
43 SPI_CS#_EXT Output
44 CGBC_SCL OD
45 SPI_MISO_EXT Input
46 BIOS_DISABLE# Input
47 SPI_CLK_EXT Output
48 SPI_MOSI_EXT Output
49 +5V standby Power
50 GND Ground
Connector Type
X35: 25x2 pins, 2mm pitch
Copyright © 2017 congatec AG
Onboard Description
level termination
3.3V PU 10k General purpose input at Board controller
3.3V PU 10k General purpose input at Board controller
3.3V PU 10k General purpose input at Board controller
3.3V PU 10k General purpose input at Board controller
3.3V PU 10k General purpose input at Board controller
3.3V standby S3 sleep control (suspend to RAM), active low
3.3V standby S4 sleep control (suspend do Disk), active low
3.3V standby S4 sleep control (suspend do Disk), active low
3.3V standby PU 10k connect directly to LID switch, active low
3.3V standby PU 10k connect directly to Sleep button, active low
3.3V standby PU 100k external Thermal event, active low
3.3V PD 10k Watchdog event output (Board controller), event after timer expires
3.3V PU 10k Watchdog trigger input (Board controller), timer reset, active low, use OD
pin at external device
3.3V standby PU 2k I2C bus from Board controller (general use), data
VIN 10k PD Power good signal from external PSU or Voltage Monitor. Onboard power
rails are disabled if signal is low.
3.3V standby PU 100k SPI chip select for external SPI flash
3.3V standby PU 2k I2C bus from Board controller (general use), clock
3.3V standby external SPI flash data output
3.3V standby PU 10k external SPI flash enable (boot from external SPI flash), active low
3.3V standby external SPI flash clock input
3.3V standby external SPI flash data input
5V standby +5V standby power, 500mA max.
IA50m10 56/59
