Feature Connector

The conga-IA5 provides a feature connector (X35).
Table 43 X35 Pinout Description
Pin Signal name
1 +5V
2 GND
3 LAD0
4 LAD1
5 LAD2
6 LAD3
7 LFRAME#
8 SERIRQ#
9 LPC_CLK_EXT
10 PLT_RST_BUF#
11 SMB_DAT_EXT
12 SMB_CLK_EXT
13 SMB_ALERT#_EXT Input
14 GND
15 TX_FEAT
16 RX_FEAT
17 GPO0
18 GPO1
19 GPO2
20 GPO3
21 GPO4
22 GPO5
23 GPO6
24 GPO7
25 GPI0
26 GPI1
27 GPI2
Copyright © 2017 congatec AG
Pin Type Voltage Onboard
level termination
Power 5V
Ground
I/O 3.3V
I/O 3.3V
I/O 3.3V
I/O 3.3V
Output 3.3V
I/O 3.3V
Output 3.3V
Output 3.3V standby
I/OD 3.3V standby PU 2k
OD 3.3V standby PU 2k
3.3V standby PU 2k
Ground
Output 3.3V
Input 3.3V
Output 3.3V PU 10k
Output 3.3V PU 10k
Output 3.3V PU 10k
Output 3.3V PU 10k
Output 3.3V PU 10k
Output 3.3V PU 10k
Output 3.3V PU 10k
Output 3.3V PU 10k
Input 3.3V PU 10k
Input 3.3V PU 10k
Input 3.3V PU 10k
Description
+5V runtime power output, 500mA max.
LPC command, address, data 0
LPC command, address, data 1
LPC command, address, data 2
LPC command, address, data 3
LPC frame (start of cycle)
Serial Interrupt Request
25MHz clock signal for external LPC device
System reset, active low
SMBus data
SMBUs clock output, up to 100kHz
SMBus Alert (system wake or SMI), active low
UART port from SoC, TX (assembly option UART from Board controller)
UART port from SoC, RX (assembly option UART from Board controller)
General purpose output from Super IO (LPC)
General purpose output from Super IO (LPC)
General purpose output from Super IO (LPC)
General purpose output from Super IO (LPC)
General purpose output from Super IO (LPC)
General purpose output from Super IO (LPC)
General purpose output from Super IO (LPC)
General purpose output from Super IO (LPC)
General purpose input at Board controller
General purpose input at Board controller
General purpose input at Board controller
