1.2.2
Optional Accessories
Table 3
Cooling Solutions
Article
conga-PA5/HSP-T
conga-PA5/i-HSP-T
conga-PA5/CSP-T
conga-PA5/i-CSP-T
conga-PA5/HSP-B
conga-PA5/i-HSP-B
Table 4
Cables
Article
conga-PA5 Cable Kit
cab-Pico-ITX-LVDS
cab-Pico-ITX-Backlight
cab-Pico-ITX-RS232
cab-Pico-ITX-RS422
cab-Pico-ITX-RS485
cab-Pico-ITX-GPIO
cab-Pico-ITX-Buttons-LED
cab-Pico-ITX-Power
Table 5
Power Supplies
Article
Power Supply 60W
Copyright © 2017 congatec GmbH
PN
Description
048150
Heatspreader solution for conga-PA5 based on Pentium and Celeron processors. All standoffs are with M2.5 thread.
048151
Heatspreader solution for conga-PA5 based on Atom E39xx processors. All standoffs are with M2.5 thread.
048152
Passive cooling solution for conga-PA5 based on Pentium and Celeron processors and heat sink with 12mm heatsink fins. All
standoffs are with M2.5 thread.
048153
Passive cooling solution for conga-PA5 based on Atom E39xx processors with 12mm heatsink fins. All standoffs are with M2.5 thread.
048154
Heatspreader solution for conga-PA5 based on Pentium and Celeron processors. All standoffs are with 2.7mm bore hole.
048155
Heatspreader solution for conga-PA5 based on Atom E39xx processors. All standoffs are with 2.7mm bore hole.
PN
Description
14000203
Cable Kit for conga-PA5 containing cab-Pico-ITX-USB2.0-Twin, cab-Pico-ITX-Audio Cable Adapter, cab-Pico-ITX-
Buttons-LED, cab-Pico-ITX-GPIO, cab-Pico-ITX-RS232, cab-Pico-ITX-RS485, cab-Pico-ITX-External-Power, cab-Pico-
ITX-Feature, cab-Pico-ITX-SATA-Power, SATA Cable and Mini-PCIe full-size card extender
14000211
LVDS data cable for Pico-ITX to connect LCD panel AUO G170EG01 V.1
(panel part number #10000132 17'' LVDS Panel G170EG01 V.1)
14000206
Backlight power cable for Pico-ITX to connect LCD panel AUO G170EG01 V.1
(panel part number #10000132 17'' LVDS Panel G170EG01 V.1)
14000152
RS232 internal cable adapter, DSUB9 male, length 150mm
14000153
RS422 cable adapter, DSUB9 male, with embedded termination, length 150mm
14000154
RS485 cable adapter, DSUB9 male, with embedded termination, length 150mm
14000151
GPIO cable, free end, length 150 mm
14000147
Buttons and LEDs cable, length 150 mm
14000172
Internal power cable for industrial versions of conga-PA5, length 150 mm
PN
Description
10000470
PSU, 60W, 12V / 5A, Plug 5.5x2.5mm / 10mm length
PA50m112
15/48
