Note
The maxmimum current is 1.2A. Only one USB port is supported on this connector. The signals for the second USB port are not connected.
congatec offers a cable for this connector (see section 1.2.2 "Optional Accessories"). For more information, contact congatec technical
solution department.
Caution
The maximum cable length of a USB 2.0 device connected to this header shall not exceed 3 meters in order to comply to EN 55024:2010.
5.5.3

USB 2.0 Header

The conga-IA5 offers one USB 2.0 header (X15).
Table 29 X15 Pinout Description
Pin Signal
1 +5V
2 D-
3 D+
4 GND
5 No Pin
Connector Type
X15: 5x1 pins, 2.54mm pitch
Note
The maximum current is 0.5A. congatec offers a cable for connector X15 (see section 1.2.2 "Optional Accessories"). For more information,
contact congatec technical solution department.
Caution
The maximum cable length of a USB 2.0 device connected to this header shall not exceed 3 meters in order to comply to EN 55024:2010.
Copyright © 2017 congatec AG
X15
No Pin
IA50m10 34/59
