Icom RS-BA1 Installation Manual page 89

4
SETTINGS FOR A REMOTE STATION PC
■ Server registration
D To add a Server (Continued)
Enter the User ID and Password.
3
1. Enter the user ID and password that are
registered in the server.
• When connecting to the network through a
PC, enter the user ID and password that are
registered in the Base station's Remote Utility.
• When connecting to the network directly, enter
the user ID and password that are registered in
the radio.
2. Click <Next>>.
• After clicking <Next>>, connects to the Server.
Adding the Server has completed.
4
1. Enter the Server Description.
L The Server Address or Network Name is
entered by default.
2. Click <Finish>.
NOTE:
If you cannot connect to the Server, the error
screen is displayed.
Click <<Back>, and confirm the settings.
61
1Enter
2Click
1Enter
2Click
