WHEN CONNECTING TO THE NETWORK THROUGH A PC

■ Connecting the radio to the Base station's PC

Before connecting the radio to the PC, please finish the installation for the Base station's PC and the Remote
station's PC, using the RS-BA1 Preparations.
D Select the connection pattern
Check the connector type on your radio and see the following chart to connect your radio to the Base station's
PC.
To connect an Icom CI-V command capable radio to the Base station's PC, you have to make connections for
control command and audio communication.
RS-BA1 operation with the Base station's PC connected to the radio's ACC socket, MIC connector, or S/P DIF
jack for audio communication cannot be guaranteed.
Radio's connector
When connecting
to the radio's [USB]
port
When connecting
to the radio's
[REMOTE] jack
When connecting
to the radio's [RS-
232C] port
*1 When you turn your radio ON or OFF from the Remote Controller, connect to the radio's [Remote] jack.
*2 When you turn your radio ON or OFF from the Remote Controller, connect to the radio's [Remote] jack or to
the network directly.
Control command
Through a USB cable
Through an audio cable connected
Through the
between the PC's audio terminal
CT-17 -
ci v level
and the radio's [ACC] socket or
converter
[MIC] connector
Through an audio cable connected
Through an RS- between the PC's audio terminal
232C cable and the radio's [ACC] socket, [MIC]
connector or [S/P DIF] jack
Outline
Audio
16
Model Ref.
IC-7100/IC-7200/
IC-7300/IC-7410/
IC-7600 *1 /IC- p. 17
7610/IC-7850/IC-
7851/IC-9100
All p. 18
IC-7700/IC-7800 *2 p. 19
