TCP/IP Settings

Within »Device Para / TCP/IP/TCP/IP Config« menu, the TCP/IP settings have to be set.
The first-time setting of the TCP/IP Parameters can be done at the panel (HMI) only.
Set the TCP/IP Parameters:
Call up »Device parameter/TCP/IP/TCP/IP Config« at the HMI (panel) and set the following parameters:
TCP/IP address;
Subnetmask; and
Gateway.
Warning: Mixing up IP Addresses
(In case there is more than one protective device within the TCP/IP network or
establishing an unintentional wrong connection to a protective device based on a
wrong entered IP address.
Transferring parameters into the wrong protective device might lead to death,
personal injury, or damage of electrical equipment.
In order to prevent faulty connections, the User MUST document and maintain a list
with the IP addresses of any switchboard/protective devices.
The User MUST double check the IP addresses of the connection that is to be
established. That means, the User MUST first read out the IP address at the HMI of
the device (within menu [Device para/TCP IP]) then compare the IP address with the
list. If the addresses are identical, establish the connection. If they are not, DO NOT
establish the connection.
Establishing a connection via TCP/IP to the device is only possible if the
device is equipped with an Ethernet interface (RJ45).
Contact your IT administrator in order to establish the network connection.
