Environmental Tests

Classification:
IEC 60068-1
IEC 60721-3-1
IEC 60721-3-2
IEC 60721-3-3
Test Ad: Cold
IEC 60068-2-1
Test Bd: Dry Heat
IEC 60068-2-2
Test Cab: Damp Heat (Steady State)
IEC 60255 (6.12.3.6)
IEC 60068-2-78
Test Db: Damp Heat (Cyclic)
IEC 60068-2-30
EDR-5000
Climatic
Classification
Classification of ambient conditions (Sto-
rage)
Classification of ambient conditions
(Transportation)
Classification of ambient conditions
(Stationary use at weather protected
locations)
Temperature
Test duration
Temperature
Relative humidity
Test duration
Temperature
Relative humidity
Test duration
Temperature
Relative humidity
Cycles (12 + 12-hour)
www.eaton.com
20/060/56
1K5/1B1/1C1L/1S1/1M2
but min. -30°C (-22°F)
2K2/2B1/2C1/2S1/2M2
but min. -30°C (-22°F)
3K6/3B1/3C1/3S1/3M2
but min. -20°C (-4°F) /max 60°C
(140°F)
-20°C (-4°F)
16 h
60°C (140°F)
<50%
72 h
60°C (140°F)
95%
56 days
60°C (140°F)
95%
2
