Voltage and Residual Voltage Measurement

Nominal Voltages:
Max. Measuring Range:
Continuous Loading Capacity:
Power Consumption:
Frequency Range:
Terminals:

Frequency Measurement

Nominal Frequencies:
EDR-5000
60 - 520 V (can be configured)
800 Vac
800 Vac
at Vn = 100 V S = 22 mVA
at Vn = 110 V S = 25 mVA
at Vn = 230 V S = 110 mVA
at Vn = 400 V S = 330 mVA
50 Hz or 60 Hz ±10%
Screw-type terminals
50 Hz / 60 Hz
