Align the triangular part (b) of the 3-Inch Paper Core Attachment (a) with the triangular part (c) of the Roll
Holder as shown, and insert the 3-Inch Paper Core Attachment into the Roll Holder.
Use the Holder Stopper for 3-inch paper cores.
• Borderless printing on A1 or A2 rolls
Attach the included Spacer for Borderless Printing to the Roll Holder.
Insert the protrusions (b) of the Spacer for Borderless Printing (a) into the holes (c) of the Roll Holder, as
shown.
3.
With the Roll Holder resting horizontally and the edge of the roll paper facing forward as shown, insert the roll
in the Roll Holder from the left. Insert the roll firmly until it touches the flange (a) of the Roll Holder, leaving no
gap.
