Chapter 4
• Port0 Bit6 Direction – [IN; OUT]
• Port0 Bit7 Direction – [IN; OUT]
• Port1 Function – [GPIO; PWM16. .PWM23]
• Port1 Bit2 Direction – [IN; OUT]
• Port1 Bit3 Direction – [IN; OUT]
• Port1 Bit4 Direction – [IN; OUT]
• Port1 Bit5 Direction – [IN; OUT]
• Port1 Bit6 Direction – [IN; OUT]
• Port1 Bit7 Direction – [IN; OUT]
• Port2 Function – [GPIO; 8051 P2; PWM16. .PWM23]
• Port2 Bit0 Direction – [IN; OUT]
• Port2 Bit1 Direction – [IN; OUT]
• Port2 Bit2 Direction – [IN; OUT]
• Port2 Bit3 Direction – [IN; OUT]
• Port2 Bit4 Direction – [IN; OUT]
• Port2 Bit5 Direction – [IN; OUT]
• Port2 Bit6 Direction – [IN; OUT]
• Port2 Bit7 Direction – [IN; OUT]
• Port3 Bit0 Function – [GPIO; 8051 P3; SPI]
- Direction – [IN; OUT]
• Port3 Bit1 Function – [GPIO]
- Direction – [IN; OUT]
• Port3 Bit2 Function – [GPIO]
- Direction – [IN; OUT]
• Port3 Bit3 Function – [GPIO]
- Direction – [IN; OUT]
• Port3 Bit4 Function – [GPIO; I2C]
- Direction – [IN; OUT]
• Port3 Bit5 Function – [GPIO]
- Direction – [IN; OUT]
• Port3 Bit6 Function – [GPIO; I2C]
- Direction – [IN; OUT]
• Port3 Bit7 Function – [GPIO]
- Direction – [IN; OUT]
